BOXER-6405M-A1-1011
Intel® N3350
BOXER-6405M-A2-1011
Intel® N4200
Fanless Box PC com processadores Intel® Celeron/ Pentium
- Slim Boxer Design: 42mm
- Rich I/O, Design for Auto System Control
- Wide Operating Temperature -20°C ~ 60°C
- Gigabit Ethernet x 2, USB x 4
- Support Wallmount
The BOXER-6405M is an embedded box computer designed for many different industrial applications. Powered by an Intel Pentium or Celeron processor, and support for up to 8GB of DDR3L SODIMM memory, it features a full sized and a half-sized mini-PCIe slot supporting expansion options including mSATA, SIM Card, and PCIe.
SYSTEM | |
CPU | Intel® Celeron/Pentium™ processor |
CHIPSET | Intel® System on Chip |
SYSTEM MEMORY | DDR3L SODIMM slot x 1 Supports 1867MHz and up to 8GB |
DISPLAY INTERFACE | HDMI type A x 1 for HDMI v1.4b VGA x 1 |
STORAGE DEVICE | HDD/SSD, (mSATA BOM option) |
ETHERNET | Intel® i211-AT x 2 |
I/O | Power Button x 1 USB Type A x 4 for USB 3.2 Gen 1 HDMI type A x 1 for HDMI v1.4b RJ-45 x 2 for GbE LAN with LED indicator ( i211-AT x 2) Power input x 1 3-pin terminal block in default (+, - , GND) Co-layout 3-pin terminal block & lockable DC-in jack,) Co-layout internal DC Mic-in x 1, Line-out x 1 RS-232/422/485 x 4 with automatic flow control (switch by BIOS) VGA x 1 Remote On/Off Antenna opening x 2 |
EXPANSION | Full-size Mini PCIe slot x 1 (PCIe/USB/SIM slot), one screw Half-size Minicard slot x 1 (optional for mSATA,PCIE/mSATA) |
INDICATOR | Power LED x 1, HDD active LED x 1 |
OS SUPPORT | Windows® 10, Windows® 10 IoT, Linux |
POWER SUPPLY | |
POWER REQUIREMENT | 3-pin Phoenix DC Input 9~24V without power protection |
MECHANICAL | |
MOUNTING | Wallmount |
DIMENSIONS (W X H X D) | 6.54" x 4.2" x 1.65" (166mm x 106.6mm x 42mm) |
GROSS WEIGHT | 3.6 lb (1.6kg) |
NET WEIGHT | 1.7 lb (0.8 kg) |
ENVIRONMENTAL | |
OPERATING TEMPERATURE | -4°F ~ 140°F (-20°C ~ 60°C) with W.T. mSATA (according to IEC68-2-14 with 0.5 m/s AirFlow; with industrial decives) |
STORAGE TEMPERATURE | -22°F ~ 140°F (-30°C ~ 60°C) |
STORAGE HUMIDITY | 95% @ 40°C, non-condensing |
ANTI-VIBRATION | 3 Grms/ 5 ~ 500Hz/ operation – mSATA 1 Grms /5 ~ 500Hz/ operation - HDD |
CERTIFICATION | CE/FCC class A |
Ordering Information [BOXER-6405M]
PART NUMBER | BOXER-6405M-A1-1011 | BOXER-6405M-A2-1011 |
---|---|---|
CPU | Intel® N3350 | Intel® N4200 |
RAM | — | — |
LAN | 2 | 2 |
USB | USB 3.2 Gen 1 x 4 | USB 3.2 Gen 1 x 4 |
RS-232 | — | — |
RS-232/422/485 | 4 | 4 |
DIGITAL I/O | — | — |
AUDIO | MIC-in, Line-out | MIC-in, Line-out |
STORAGE | SSD/HDD x 1 | SSD/HDD x 1 |
DISPLAY | VGA/HDMI x1 | VGA/HDMI x1 |
EXPANSION | Full-size Minicard x1 Half-size Minicard x 1 |
Full-size Minicard x1 Half-size Minicard x 1 |
MOUNTING | Wallmount | Wallmount |
POWER | 9~24V | 9~24V |
OPERATION TEMP | -20°C ~ 60°C | -20°C ~ 60°C |
- Wallmount Bracket x 2
- 3 Pin DC-In Power Connector x 1
- BOXER-6405M
125530040F | Power Adapter |
1702031802 | Power Cord (US type) |
1702031803 | Power Cord (European Type) |
170203180E | Power Cord (Japanese Type) |
9741238H00 | WiFi Module & Antenna |
9741EG25G0 | 4G Module & Antenna (for global) |
9741640404 | Din Rail Mount Kit |
