com IVA
sem IVA
1,992.60€
sem IVA
1,620.00€
Sku: FT10I5CAPOB
Type de produit:
Panel-PC Alta Performance
Vendeur:
Faytech
FT10I5CAPOB
- Intel® Core™ i5-7300U
- 8GB RAM, SSD 128GB Industrial
- Suporta Win10, Linux (32Bit, 64Bit)
- Tratamento de superfície anti-reflexo
- Vidro de cobertura de 1,1 mm com dureza de superfície 7H
- Painel Multi Touch Capacitivo de 10 toques
- Protecção IP65 frontal patenteada com selo de silicone
- Optically bonded
- W-LAN integrada
- Suporta fixação por grampos
- Garantia de 2 anos
Caraterísticas
Especificações
Downloads
Opcionais
Caraterísticas
IP Rating
Protection
IP65 Front/ IP40 Back
PC System
CPU
Intel i5-7300U Kaby Lake
RAM
8GB
Memory
128GB
Operating System
Ubuntu
LCD Panel
Display Size
9,7"
Display Format
4:3
Physical Resolution
1024x768
Brightness
300 cd/m²
Optical Bonding
Optical Bonding
Coverglass
1,1mm
Operation / Mechanical
Housing
Rubber Frame
Backlight Type
Edge Backlight
Touch Panel
Touch Technology
capacative
Power
Power Supply
12V
External connections
HDMI
1
VGA
0
DP
1
USB 2.0
0
USB 3.0
4
Especificações
Product name | 10" Capacitive Touch PC (i5-7300U) |
Article code / EAN number | FT10I5CAPOB / 6920734000111 |
CPU | Intel® Core™ i5-7300U Processor Kaby Lake |
Graphic GPU | Intel® HD Graphics |
Audio | Realtek ALC3236 Audio CODEC |
Memory | 8GB DDR4 non-ECC (max. 16GB) |
Storage | faytech Industrial 128GB SSD |
Network | 2x Realtek PCIe GB LAN 8111G (1000Mbps), M.2 E-key Wi-Fi module |
Driver Support | Win10; Linux; 32Bit/64Bit |
Pre-installed OS | Linux Ubuntu |
IP65 Front / IP40 Back |
Screen diagonal (Inch/cm) | 9.7/24.64 |
Display active screen size (cm) | 19.70×14.70 |
Aspect ratio | 4:3 |
Physical resolution | 1024x768 |
External maximum showable resolution - HDMI, DP | 1920×1200 |
Colours displayed | 16.7M |
Brightness (cd/m²) | 350 |
Contrast | 800:1 |
Typical reaction time Tr/ Tf (ms) | 10/15 |
Visual Angle horizontal/vertical (°) | 170/170 |
Backlight / Backlight Lifetime (hours) | LED / 20,000 |
Touch Technology | Projected Capacitive 10-point Multitouch |
Touch Connector | USB |
Touch Life (Contacts) | Unlimited |
Surface Hardness | 7H |
Surface Treatment | Anti-glare (chemical etched) |
Operating Temperature (°C) | -10 ~ +60 |
Humidity Range (RH) | 10% - 90% |
Net weight (kg) | 2.00 |
Gross weight (kg) | 2.90 (incl. cartonage) |
Housing material | Rubber front case, Aluminum IPC back case |
Housing (mm) L × W × H | 245.0 × 195.8 × 59.0 |
Cut-out for clamp supports (mm) L × H | 231.0 × 190.0 |
Max. wall thickness for clamp supports (mm) | 5.0 |
Amount of clamps required | 3 |
Mounting | VESA 100 |
Power Indicator | Green LED |
Power Supply | 100-240V ACDC active switching; 12V DC-Out |
Working Power (V) | 12 |
Power Consumption (W) | 28 |
Stand-By Consumption (W) | <1 |
1x SO-DIMM, max. 16 GB, DDR4 1866/2133 non-ECC, Single channel memory |
3x RS232/RS485 COM connectors, switchable in BIOS |
2x LCD Backlight control/LCD panel voltage box |
1x 5V/12V SATA power connector |
1x 12V DC power connector (2-pin) |
1x 4-pin SATA power connector |
1x S/PDIF output pin header |
1x 8-bit Digital I/O interface |
1x Line-out / Mic-in header |
1x Front Panel box header |
1x Serial ATA 6Gb/s |
1x MIPI CSI connector |
1x LVDS box header |
2x USB 3.0 box header |
1x 12V DC-In (screwable) |
1x HDMI |
1x DisplayPort |
4x USB 3.0 ports |
1x MIC-In & EAR-Out |
1x 10-PIN DIO as RJ50 |
1x W-LAN antenna connector (RP-SMA male) |
2x COM port Full-PIN - RS232/485; 5V/12V |
2x COM port 3-PIN - RX, TX, GND; RS232/485; 5V/12V |
2x 10/100/1000Mbit RJ45 Ports |
1x 2.5" module slot, changeable SSD included |
1x mSATA full size (occupied by SSD) |
1x M.2 E-Key Slot (occupied by Wifi card) |
1x SATA connector |
1x External PCIe x1 Straddle connector |
Power Supply (see Power section) |
W-LAN antenna (RP-SMA female) |
Short Installation Manual |
Standard Stand |
Downloads
Opcionais
Sistemas Operativos Microsoft para adicionar ao seu Panel PC
94.00€
SO Win 10 IoT Enterprise 2019 LTSB (Entry)
Chave de licença + instalação (OEM)
* Deve ser solicitada junto com a mesma quantidade de equipamentos
Entrega Normal | 5 a 7 dias úteis
Entrega Urgente | 3 a 5 dias úteis
*salvo rutura de stock
Trabalhamos intensamente cumprir os prazos de entrega anunciados. No entanto, enfrentamos uma escassez global relativamente a alguns componentes e fabricantes.
Em caso de dúvidas ou preocupações, entre em contacto connosco para garantir o tempo de entrega.
Poderemos aconselhar sobre a disponibilidade de hardware alternativo e fornecer recomendações de componentes disponíveis para opções de envio mais rápidas.
