• Intel® Core™ 6/ 7 Geração, Q170
  • DDR4 SODIMM até 32GB
  • Triplo display: 2x HDMI + VGA
  • 3x Intel® i210 GLAN
  • 9~36 VDC
com IVA
1,020.90€

sem IVA
830.00€
Sku: BOXER-6639-A1-1110
Tipo de Produto: PCs Visão Artificial
Fabricante: AAEON

BOXER-6639-A1-1110

BOXER-6639-A2-1110

BOXER-6639-A3-1110

BOXER-6639-A4-1110

BOXER-6639-A5-1110

Fanless Embedded Box PC with Socket Type 6th Generation Intel® Processor and Q170 Chipset

  • Extreme Computing Power & Graphic Display Capability
  • Desktop Grade Socket Type Processor with Longevity Support
  • Supports DDR4 ECC or Non-ECC SODIMM, Up to 32GB
  • Supports VGA + HDMI x 2 Triple Display, HDMI 4K Display
  • Supports USB 3.2 Gen 1 x 4, USB 2.0 x 2
  • Supports Industrial-grade Intel® GbE LAN x 3
  • Supports BIOS Selectable RS-232/422/485 x 6
  • Compact Size and Easy Access Design
  • Wide Range DC 9~36V Input
  • 34-bit Digital Input and Output
Caraterísticas

Powered by 6th Gen Intel® Core™ Desktop Processor with longevity support and a flexible mechanical design to change out the CPU depending upon the customer’s needs, 2 x HDMI with 4K resolution, 3 x industrial GbE LAN with Intel® industrial-grade I210 chipset, the BOXER-6639 aims at delivering superb performance. The rugged chassis design is ideally suited for smart control systems, machine vision inspection, digital signage, surveillance and machine maker.

With features supporting extended operating temperature from -20°C to 55°C and 9 ~ 36V wide range DC input, this BOX PC enhances operation in harsh factory environments.

AAEON’s BOXER-6639, incorporated with a variety of serial I/O connectors, including 6 COM ports, 4 USB 3.2 Gen 1 and 34 channel DIO, offers flexible configuration and expansion capability. Hence, customers can efficiently wire-up multiple systems to the central controller for various automation applications.

Especificações
SYSTEM
CPU Intel® Core™ i7-7700T, 2.9 GHz
Intel® Core™ i5-7500T, 2.7 GHz
Intel® Core™ i7-6700TE, 2.4 GHz
Intel® Core™ i5-6500TE, 2.3 GHz
Intel® Core™ i3-6100TE, 2.7 GHz
Intel® Pentium® G4400TE, 2.4 GHz
Intel® Celeron® G3900TE, 2.3 GHz
CHIPSET Q170
SYSTEM MEMORY DDR4 1866/2133 SODIMM slot x 2, up to 32 GB, ECC or Non-ECC support
DISPLAY INTERFACE VGA, HDMI
STORAGE DEVICE CFast, SATA HDD/SSD (Optional: x2)
ETHERNET Intel® i210, 10/100/1000Base-TX x 3
I/O RS-232/422/485 x 6
USB 3.2 Gen 1 x 4
USB 2.0 x 2
VGA x 1
HDMI x 2
Line-out x 1
Mic-in x 1
LAN x 3
CFast slot x 1
SIM slot x 1
Antenna holes x 2
34bit DIO x 1(A2 & A4 SKU)
Power switch
Power input
Remote power switch
Reset Button
EXPANSION Full-size Mini-Card x 1 (PCI-E + USB, w/ SIM slot)
Full-size Mini-Card x 1 (PCI-E + USB, Optional for mSATA and SIM Slot)
INDICATOR Power LED
HDD active LED
OS SUPPORT Windows® 7 (32/64-bit),
Windows® 8/8.1 (64-bit) ,
Windows® 10 (64-bit)
POWER SUPPLY
POWER REQUIREMENT 9 - 36V with 3-pin terminal block
MECHANICAL
MOUNTING Wallmount, DIN Rail (Mounting Kit is optional)
DIMENSIONS (W X H X D) 10.4" x 2.6" x 6.1" (264.2mm x 66.5mm x 156.2mm)
GROSS WEIGHT 7.7 lb (3.5 kg)
NET WEIGHT 6.6 lb (3 kg)
ENVIRONMENTAL
OPERATING TEMPERATURE -4°F ~ 131°F (-20°C ~ 55°C)
(according to IEC68-2-14 with 0.5 m/s AirFlow; with industrial devices)
STORAGE TEMPERATURE -49°F ~ 176°F (-45°C ~ 80°C)
STORAGE HUMIDITY 5~95% @ 40°C, non-condensing
ANTI-VIBRATION 2 Grms/ 5 ~ 500Hz/ operation –CFast™ card
1 Grms/ 5~ 500Hz/ operation – HDD
ANTI-SHOCK -
CERTIFICATION CE/FCC class A



Ordering Information [BOXER-6639]

PART NUMBER BOXER-6639-A1-1110 BOXER-6639-A2-1110 BOXER-6639-A3-1010 BOXER-6639-A4-1010
CPU
RAM
LAN 3 3 3 3
USB USB 3.2 Gen 1 x 4
USB 2.0 x 2
USB 3.2 Gen 1 x 4
USB 2.0 x 2
USB 3.2 Gen 1 x 4
USB 2.0 x 2
USB 3.2 Gen 1 x 4
USB 2.0 x 2
RS-232/422/485 6 6 6 6
DIO 34 bit 34 bit
AUDIO Mic-in, Line-out Mic-in, Line-out Mic-in, Line-out Mic-in, Line-out
STORAGE 2.5” SATA Drive bay x 1, CFast™ slot x 1 2.5” SATA Drive bay x 1, CFast™ slot x 1 2.5” SATA Drive bay x 2, CFast™ slot x 1 2.5” SATA Drive bay x 2, CFast™ slot x 1
DISPLAY VGA x 1, HDMI x 2 VGA x 1, HDMI x 2 VGA x 1, HDMI x 2 VGA x 1, HDMI x 2
EXPANSION Full-size Mini-Card x 2 Full-size Mini-Card x 2 Full-size Mini-Card x 2 Full-size Mini-Card x 2
MOUNTING Wallmount Wallmount Wallmount Wallmount
POWER 9-36V 9-36V 9-36V 9-36V
TEMP -4°F ~ 131°F (-20°C ~ 55°C) -4°F ~ 131°F (-20°C ~ 55°C) -4°F ~ 131°F (-20°C ~ 55°C) -4°F ~ 131°F (-20°C ~ 55°C)
Packing List



  • Wallmount Bracket x 2
  • Screw Package x 1
  • BOXER-6639



Acessórios
1255X00059 Power Adapter
1702031802 Power Cord (US Type)
1702031803 Power Cord (Europe)
170203180E Power Cord (Japan)
9741663902 Din Rail Mount Kit
9741663900 I/O Dust Cover Kit.For BOXER-6639(A1 & A3 sku)
