| SYSTEM | |
| CPU | 12th Generation Intel® Core™, TDP Max. 65W Intel® Core™ i9-12900TE/i9-12900E Intel® Core™ i7-12700TE/i7-12700E Intel® Core™ i5-12500TE/i5-12500E Intel® Core™ i3-12100TE/i3-12100E 13th Generation Intel® Core™, TDP Max. 65W Intel® Core™ i9-13900TE/i9-13900E Intel® Core™ i7-13700E Intel® Core™ i5-13500E Intel® Core™ i3-13100TE |
| CHIPSET | Q670E |
| SYSTEM MEMORY | DDR5 4800Mhz U-DIMM x 4, up to 128GB |
| DISPLAY INTERFACE | HDMI x 2 (Type-A) Display Port x 2 |
| STORAGE DEVICE | 2.5” SATA Drive Bay x 2 (external, swappable) M.2 2280 M-Key x 2 (PCIe Gen 4 [x4]) 3.5” SATA Drive Bay (internal, non-swappable, optional) |
| ETHERNET | 2.5GbE x 3 (Intel® I226-IT) GbE x 1 with LED Indicator (Intel® I219-LM) |
| I/O | HDMI x 2, Display Port x 2 RJ-45 x 4 3.2 Gen 2 x 8 (Type-A) DB-9 Male x 6 for RS-232/422/485 (Autoflow, Programmable) DB-15 Male x 1 for 8-bit DIO Audio (Mic-in/Line-out) DC 19 ~ 36V 3-pin Terminal Block Connector Power Button with LED x 1 Remote Power On/Off x 1 Reset Button x 1 |
| EXPANSION | M.2 2230 E-Key x 1 M.2 3052 B-Key w/SIM x 1 M.2 2280 M-Key/B+M-Key x 2 Full-Size Mini Card x 1 (PCIe + USB) |
| INDICATOR | — |
| OS SUPPORT | Windows® 10 IoT Enterprise LTSC 2021 Windows® 11 Pro Linux Ubuntu 22.04 |
| POWER SUPPLY | |
| POWER REQUIREMENT | DC 19~36V 3-pin Terminal Block |
| MECHANICAL | |
| MOUNTING | Wallmount |
| DIMENSIONS (W X H X D) | 7.35’’ x 8.92’’ x 14.76’’ (186.8 x 226.5 x 375 mm)(Without brackets) 7.35’’ x 9.19’’ x 16.50’’ (186.8 x 233.5 x 419 mm)(With brackets) |
| GROSS WEIGHT | TBD |
| NET WEIGHT | TBD |
| ENVIRONMENTAL | |
| OPERATING TEMPERATURE | -4°F ~ 113°F (-20°C ~ 45°C), according to IEC68-2 with 0.5 m/s AirFlow (w/ Industrial wide Temp. SSD/RAM) |
| STORAGE TEMPERATURE | -40°F ~ 176°F (-40°C ~ 80°C) |
| STORAGE HUMIDITY | 5 ~ 95% @ 40°C, non-condensing |
| ANTI-VIBRATION | 3 Grms/ 5 ~ 500Hz/ operation (with SSD) |
| ANTI-SHOCK | 50G, IEC 68-2-27, half sine, 11 ms duration (with SSD) |
| CERTIFICATION | CE/FCC Class A |
| 1255903300 | 330W Power Adapter |
| 1255X00021 | 480W Power Adapter (DIN Rail) |
| 1702031802 | Power Cord (US type) |
| 1702031803 | Power Cord (European Type) |
| 170203180E | Power Cord (Japanese Type) |
| 9741238H00 | WiFi Module & Antenna |
| 9741EG25G0 | 4G Module & Antenna (for global) |
| 9741EC25A0 | 4G Module & Antenna (for USA-AT&T) |
| 9741EC25V0 | 4G Module & Antenna (for USA-Verizon) |
| 9651500Q00 | 5G Module & Antenna (for USA & EMEA, Asia) |
