Display |
|
|
Front Bezel |
– IP65, NEMA 4 rugged protection, metal front bezel |
|
Display Type |
– 10.4″ With LED Backlight |
|
Brightness (cd/m²) |
– 230 nits |
|
Display Color |
– 262K |
|
Resolution |
– 800 x600 @ 60Hz |
|
Viewing Angle (H/V) |
– 160°/130° |
|
Pixel Pitch |
– 0.264 x 0.264 mm |
|
Aspect Ratio |
– 4:3 |
|
Contrast Ratio |
– 500:1 |
|
Operating Temperature |
– -20 ~70° C |
|
Touch Screen |
|
|
Type |
– 5 wires analog resistive type |
|
Active Range |
– 211.58 x 158.75mm ±0.2mm |
|
Transparency |
– 80 ±3% |
|
Surface Hardness |
– ≧3H (ASTM D3363, pressure 750g/45°) |
|
Operating Force |
– ≦ 80g |
|
Knock test |
– 10,000,000 times keystrokes |
|
Operating Temperature |
– -20 ~70° C |
|
Main System |
|
|
CPU |
– Intel® Bay Trail-M N2930 1.83GHz/QC |
|
RAM |
– 4G 1333MHz DDR3L SAMSUNG DRAM |
|
BIOS |
– 64MB SPI Flash ROM |
|
Storage |
– 1 * 2.5” SATA HDD (SATA-2) |
|
Watchdog Timer |
– 256 levels, 0~255 sec. |
|
OS Support |
– Windows 7 / 8.1 / 10 / Linux (Option) |
|
I/O Connector |
|
|
I/O Ports and Switches |
– 1 * USB3.0 |
|
Expansion Interface |
|
|
Expansion |
– 1 * PCI-E mini card for wifi or 3G |
|
Power |
|
|
Power Input |
– AC version: 100~240V AC-DC 60W power adapter or |
|
Power Consumption |
– 23W |
|
Dimensions |
|
|
Case Dimensions |
– 284.0*230.0*37.0mm |
|
Certifications |
|
|
Certifications |
– CE, FCC, IP65 |
|
Environment |
|
|
Temperature |
– Operating Temperature: -10 ~ 60° C (with W.T. DRAM/HDD in airflow condition) |
|
Shock |
– Operating: 15G，11ms duration |
|
Vibration |
– Operating: 5~500Hz/1 Grms |
|
Warranty |
|
|
Warranty |
– 2 Years Limited Warranty(Panel and Touch is only Warranty 1 Year) |
* Specifications subject to change without notice, not responsible for typographical errors. Does not include HDD or OS.
Entrega Normal | 5 a 7 dias úteis
Entrega Urgente | 3 a 5 dias úteis
*salvo rutura de stock
Trabalhamos intensamente cumprir os prazos de entrega anunciados. No entanto, enfrentamos uma escassez global relativamente a alguns componentes e fabricantes.
Em caso de dúvidas ou preocupações, entre em contacto connosco para garantir o tempo de entrega.
Poderemos aconselhar sobre a disponibilidade de hardware alternativo e fornecer recomendações de componentes disponíveis para opções de envio mais rápidas.
