Switch LNX-800AG (8* 10/100/1000Tx) SLIM

com IVA
221.40€

sem IVA
180.00€
Sku: LNX-800AG
Type de produit: Switches Não-Gerenciáveis
Vendeur: Antaira

LNX-800AG

    Especificações

    • Network Broadcast Storm Protection
    • 8-Ports 10/100/1000Tx Fast Ethernet
    • Supports Auto MDI/MDI-X Function
    • Store-and-Forward Switching Architecture
    • 16Gbps Back-Plane (Switching Fabric)
    • 8K MAC Address Table
    • 9.6Kbytes Jumbo Frame Support
    • Surge Protection: 3,000 VDC Support
    • ESD Protection: 6,000 VDC Support
    • Redundant Power Input Design – 12~48VDC
    • Built-in 1 Relay Output for Port Break Alarm
    • IP30 Rugged Aluminum Case Design
    • DIN-Rail and Wall Mount Support
    • Operating Temperature Range - STD: -10° to 70° C
    • 5-Year Warranty

    Descrição

    Antaira’s LNX-800AG is a smart 8-Port Industrial Gigabit Unmanaged Ethernet Switch that is 10/100/1000Tx and can automatically sense transmission speeds of 10/100/1000 Mbps. The RJ-45 interface can also be auto-detected, so MDI or MDI-X is automatically selected and a crossover cable is not required. All Ethernet ports have memory buffers that support the store-and-forward mechanism.


    LNX-800AG_datasheet



    Características

    Standards IEEE 802.3, IEEE 802.3u, IEEE802.3ab
    Operating Temperature -10° ~ 70° C (14° ~ 158° F)
    Storage Temperature -40° ~ 85° C
    Humidity 5% ~ 95% non-condensing
    Dimensions IP-30, 30 x 140 x 95 mm (1.18 x 5.51 x 3.74 inches)
    Protocols CSMA/CD
    Power Input 12 ~ 48 VDC, Redundant Input
    Power Consumption 7.788W @ 12VDC, 7.392W @ 48VDC
    Housing Metal, IP30 protection
    Weight Unit Weight: 1-lbs. Shipping Weight: 1.5 lbs
    Certifications FCC, CE, UL, UL Class 1 Div.2
    Warranty 5 Years
