NUC-UPS (6-38V Input, 12V Output 5A, formato NUC)

  • Input 6-38V
  • Output 12V (5A)
  • Interface USB
  • Pilhas Li-Ion (3.7V)
  • Programável
com IVA
151.04€

sem IVA
122.80€
Sku: NUC-UPS
Tipo de Produto: Fontes UPS
Fabricante: Mini-BOX

NUC-UPS

Entrada 6-38V, saída d12V 5A, interface de backup programável, formato NUC

  • 2.5" drive footprint mounts
  • Input 6-38V
  • 12V output, synchronous buck-boost
  • Output 5A
  • 4S x 18650* Li-Ion (batteries not included)
  • 3 state charger (precharge, CC, CV)
  • Battery balancing
  • Charge voltage 4x4.2V, charge current 1A, precharge current ~0.3A
  • Coulomb counting
  • Battery temperature monitoring for each cell
  • Missing battery cells detection
  • Temperature compensated charge
  • Motherboard Start/Stop button and header
  • 5uA- in Deep Sleep mode
  • 250uA- in Standby mode
  • Windows detects device as “Battery”, with no special drivers required**

Caraterísticas
NUC-UPS was designed to provide regulated power output from the widest input voltage (6-38V) or battery backup, microprocessor assisted Li-Ion battery charging and cell balancing in a single PCBA. Battery cells are inserted in the device, no need for special cabling between cells and UPS.

The UPS contains a 60V synchronous buck-boost converter with high accuracy voltage and current regulation and automatic system power path selection from adapter or battery. It charges the battery in three phases: preconditioning, constant current mode and constant voltage mode.

NUC-UPS has Windows support allowing developers to interface to custom applications.

Output and settings can be monitored via custom software applications, 2nd battery status shows on all Windows systems. Windows detects device as “Battery”, no special drivers required.

Downloads
Dimensões
Manual
Software download
Linux Software
Bibliotecas
