• ESP32 S3 8MB PSRAM
  • 5' LCD Touch Display
  • 4x Analog In 0-10V
  • 4x Digital In
  • 4xTransistor Out
com IVA
207.84€

sem IVA
168.98€
Sku: ESP-HMI-5C-VI
Tipo de Produto: Arduino HMIs
Fabricante: NORVI

ESP-HMI-5C-VI

ESP32-based Human Machine Interface

O HMI NORVI ESP32 é um HMI programável + controlador com suporte para LVGL (Light and Versatile Graphics Library), oferecendo aos utilizadores um ambiente gráfico rico para uma interação perfeita. E programável com Arduino, esta HMI oferece uma plataforma poderosa e versátil para criar interfaces de utilizador intuitivas, utilizando as capacidades dos microcontroladores ESP32. Além disso, a sua integração com o LVGL permite a criação de interfaces visualmente atraentes, responsivas e ricas em funcionalidades, tornando-o ideal para várias aplicações que exigem interações fáceis de utilizar, como dispositivos IoT, sistemas de automação e muito mais.

  • ESP32 S3 Integration with 8MB PSRAM
  • 5inch LCD Display with Resistive Touch
  • LVGL Technology
  • Built-in Buzzer
  • Digital Inputs
  • Analog Inputs
  • Transistor Outputs
  • Supports Industrial Voltage up to 24V DC
  • Arduino Compatibility
  • PLC functionality
ESP-HMI-5C-VI
Caraterísticas
ESP-HMI-5C-V1_specs
ESP-HMI-5C-VI

Suporta

esp32-s3-300x300
lvgl
Arduino

Comunicação

wifi
bluetooth
ethernet
RS-485

Especial

RTC
microSD
lcd

Advantages of ESP32-S3-WROOM

  1. Enhanced CPU Performance
  2. Secure Connectivity
  3. Rich Set of I/O Interfaces
  4. Advanced Security Features
  5. Low Power Consumption
  6. Integrated Peripherals
  7. AI Acceleration
  8. Compatibility and Development Support

The ESP32-S3 integrates cutting-edge features tailored for IoT applications. Firstly, its enhanced CPU performance enables faster processing, crucial for handling complex tasks efficiently. Additionally, with robust security measures like secure boot and cryptographic hardware accelerators, it ensures data integrity and confidentiality. Supporting various wireless protocols like Wi-Fi and Bluetooth, it guarantees reliable and secure connectivity, vital for IoT device communication. Moreover, its rich set of I/O interfaces, including digital and analog interfaces, GPIO pins, and integrated peripherals such as timers and UART, facilitates seamless integration with sensors and peripherals, enhancing versatility. Furthermore, its low power consumption makes it suitable for battery-operated devices. Lastly, selected variants offer AI acceleration hardware for machine learning applications at the edge. Supported by the ESP-IDF, it provides a comprehensive development ecosystem with libraries, tools, and documentation, simplifying the development process.

Advantages of LVGL Support Display

1. Lightweight and Efficient
2. Rich and Customizable Graphics
3. Easy to Use and Learn
4. Versatility and Flexibility
5. Community Support and Active Development
6. Open-Source License
7. Performance Optimization

LVGL, a versatile graphics library, offers several key benefits. Firstly, it’s lightweight and efficient, optimized for microcontrollers and resource-constrained systems. Additionally, it provides rich and customizable graphics, allowing easy adaptation to specific design requirements. Furthermore, LVGL is easy to use and learn, with comprehensive documentation and examples facilitating quick implementation. Moreover, its versatility and flexibility enable seamless integration with various input devices and display types, catering to different application needs. Furthermore, LVGL benefits from strong community support and active development, ensuring continuous improvement. Additionally, its open-source license fosters collaboration and innovation. Finally, LVGL excels in performance optimization, ensuring smooth animations and responsiveness even on devices with limited processing power.

Operating Systems and Softwares

  1. Arduino (C++)
  2. MicroPyton
  3. ESP-IDF (Espressif IoT Development Framework)

NORVI ESP32-based HMI Applications

  • Industrial Process control
  • Energy Management
  • Transportation
  • Healthcare
  • Smart Homes
  • Consumer Devices
  • Public Infrastructure Managemnet
  • Simple process controller
Especificações
Main
Range of Product NORVI HMI Controller
Product Type Programmable HMI
Certifications EN 61131-2:2007
EN 61010-1:2010+A1:2019
EN IEC 61010-2-201:2018
2014/30/EU- Electromagnetic Compatibility (EMC)
Annex III, Part B, Module C
Rated supply voltage 12 - 24V DC
Communication RS-485 Ethernet
Inputs and Outputs 4 x Digital Inputs
4 x Analog Inputs 4-20mA
4 x Transistor outputs
Displays and Visual Indicators LCD Display

Complementary
Product Unified Code ESP-HMI-5C-VI
Product Part Numbers  ESP-HMI-5C-VI

Mechanical Properties
Enclosure OP-300-B
Mounting / Installation Method DIN Panel Mount / Cutout 116 x 163 mm
Terminal Type SCREW TERMINAL
Terminal Arrangement Top and Bottom
Length 179.6 mm
Height 129.6 mm
Width 42.6 mm

Environment
IP degree of protection  IP20
Operating altitude  0 - 2000 meters
Operating Temperature  -10 - +85C (185 °F)
Storage altitude  0 - 3000 meters
Shock resistance  15 gn for 11ms
Resistance to electrostatic discharge  4kV on contact 8kV on air
Resistance to electromagnetic fields  10 V/m (80 MHz - 1GHz)
3 V/m (1.4 MHz - 2 GHz)
1 V/m (2 MHz - 3 GHz)

Electrical Characteristics
Rated Supply Voltage (V) 24V DC
Current Consumption (mA) 100mA
Recommended Power Source 2W

Processing
SOC / MCU ESP32-S3-WROOM32-1-N16R8
Flash Memory 16MB
ROM 384 KB
SRAM 512 KB
PSRAM 8 MB (Octal SPI)

Peripherals
microSD Card support
Card Type microSD
Interface SPI
SD CARD CS GPIO37
MISO GPIO19
MOSI GPIO12
SCLK GPIO13
SD Detect NOT CONNECTED

Internal RTC
RTC Chip DS3231
Backup Battery Type CR2032
Interface I2C
I2C Address 0x68
SCL Pin GPIO19
SDA Pin GPIO20

TFT LED Display
Display Driver ER-TFT050-3
Display Size 5 inch
HSYNC GPIO6
VSYNC GPIO5
DEN GPIO4
DCLK GPIO7
DISP CS GPIO39
R0 Connected to GND
R1 Connected to GND
R2 Connected to GND
R3 GPIO1
R4 GPIO41
R5 GPIO40
R6 GPIO38
R7 GPIO45
G0 Connected to GND
G1 Connected to GND
G2 GPIO48
G3 GPIO47
G4 GPIO21
G5 GPIO14
G6 GPIO9
G7 GPIO3
B0 Connected to GND
B1 Connected to GND
B2 Connected to GND
B3 GPIO8
B4 GPIO18
B5 GPIO17
B6 GPIO16
B7 GPIO15

INPUTS and OUTPUTS
Digital Inputs
Number of Digital Inputs 4
Digital Input Polarity Sink and Source
Digital Input Maximum Voltage 32V DC
Digital Input Minimum Voltage 18V DC
Maximum Switching Frequency 1 kHZ
IO Connection Via PCA9535PW
SCL - Pin 14
SDA - Pin 15

I2C Address - 0x73
Terminal Arrangement Digital Input 0 - IO0
Digital Input 1 - IO1
Digital Input 2 - IO2
Digital Input 3 - IO3

Analog Inputs
Number of Analog Inputs 4
Analog Input Measurement Range 0-10V
Analog Input Maximum Voltage 38V DC
Analog to Digital Converter (ADC) ADS1115
Analog to Digital Converter (ADC) Communication I2C
Analog to Digital Converter (ADC) Address 0x48
Terminal Arrangement A0 : Analog Input 0 - ADS1115 - 0x48 - AIN0
A1 : Analog Input 1 - ADS1115 - 0x48 - AIN1
A2 : Analog Input 2 - ADS1115 - 0x48 - AIN2
A3 : Analog Input 3 - ADS1115 - 0x48 - AIN3

Transistor Outputs
Number of Transistor Outputs 4
Transistor Output Type OPEN COLLECTOR
Maximum Sink/Source Current (mA) 100mA
Maximum Applicable Voltage 40V  DC
Maximum Switching Frequency 1 kHz
IO Connection Via PCA9535PW
SCL - Pin 14
SDA - Pin 15

I2C Address - 0x73
Terminal Arrangement TR01 - IO4
TR02 - IO5
TR03 - IO6
TR04 - IO7

RS-485 Communication
Communication Mode FULL-DUPLEX
Transceiver SP490CN-L
Unit Load 1
TX Pin GPIO3
RX Pin GPIO35

Ethernet SPI - W5500
Transceiver W5500
Speed 10BaseT/100BaseTX
Supports Auto Negotiation Yes
TX/RX Buffer Size Internal 32 Kbytes Memory
Supported Hardwired TCP/IP Protocols TCP, UDP, ICMP, IPv4, ARP, IGMP, PPPoE
Number of Simultaneous independent sockets 8
SCSn GPIO10
MISO GPIO11
MOSI GPIO13
SCLK GPIO12

IO Expander
PCA9535PW PIN Connection
1 - A0 Pulled up to 3.3V
2 - A1 Pulled up to 3.3V
3 - RESET Pulled up to 3.3V
4 - IO0 Digital Input 1
5 - IO1 Digital Input 2
6 - IO2 Digital Input 3
7 - IO3 Digital Input 4
8 - VSS GND
9 - IO4 Transistor Output 1
10 - IO5 Transistor Output 2
11 - IO6 Transistor Output 3
12 - IO7 Transistor Output 4
13 - INT Pulled up to 3.3V
14 - SCL SCL
15 - SDA SDA
16 - VDD 3.3V
