Mini PC Fanless ARM VIA Artigo A820 1.0GHz NXP i.MX 6DualLite Cortex-A9 dual-core SoC, 1GB DDR3 RAM, 4GB EMMC, Mini HDMI, 3 USB 2.0, COM, DIO, Gigabit Ethernet, 10/100Mbps Ethernet,...

  • - Preços Sem IVA incluído.

  • - Valores sujeitos a alterações.

  • - Alguns dos valores requerem confirmação no acto da encomenda.

VIA Technologies
€355.00

Mini PC Fanless ARM VIA Artigo A820 1.0GHz NXP i.MX 6DualLite Cortex-A9 dual-core SoC, 1GB DDR3 RAM, 4GB EMMC, Mini HDMI, 3 USB 2.0, COM, DIO, Gigabit Ethernet, 10/100Mbps Ethernet, Micro SD Card, miniPCIe, DC-in 5V.

  • Alta-performance 1.0GHz NXP i.MX 6DualLite ARM Cortex-A9
  • Elegante sistema fanless IoT gateway
  • Conectores I/O : COM, Digital I/O, e 2 portas USB
  • Dual Ethernet
  • Modulo de Wifi de alta-velocidade (opcional)



Barebone ARM VIA Artigo A820



VIA Artigo A820

Especificações:



Model Name ARTiGO A820
Processor 1.0GHz NXP i.MX 6DualLite ARM Cortex-A9
System Memory 1GB DDR3 SDRAM onboard
Storage 4GB eMMC Flash memory
Micro SD Card
Graphics Vivante GC880
2 Independent, integrated 3D/2D graphics processing units
Graphics engine support OpenGL® ES 2.0, OpenVG 1.1 hardware acceleration
Support MPEG-2, VC-1 video decoding up to 1080p
LAN Micrel KSZ9031RNX Gigabit Ethernet Transceiver with RGMII support
ASIX AX88772 USB 2.0 to 10/100Mbps Fast Ethernet Controller
HDMI Integrated HDMI 1.4 transmitter
USB SMSC USB2514 USB 2.0 High Speed 4-port hub controller
Expansion I/O 1 miniPCIe slot
Front Panel I/O 1 USB 2.0 port
1 DIO port supports 8 GPIO (4 GPI+4 GPO)
1 COM port for RS-232/485 supports 8-wire DTE mode with isolation feature
1 RS-232/485 select switch for COM port
1 Reset button
1 Power & Wi-Fi LED
Back Panel I/O 1 HDMI port
2 USB 2.0 ports
1 Gigabit Ethernet port
1 10/100Mbps Ethernet port
2 Antenna holes for 3G or Wi-Fi
1 DC-in jack power input connector
Bottom Panel I/O 1 miniPCIe slot
1 Micro SD card slot
1 Micro SD/SPI boot switch
Watchdog Timer Integrated watchdog timer supports two comparison points. Each comparison point can interrupt ARM core, 2nd comparison point capable of generating external interrupts on WDOG line
Power Supply 5V DC-in (Typical: 6.7W)
Operating System Linux Kernel 3.0.35
Operating Temperature 0°C to 50°C
Operating Humidity 0% ~ 90% @ 45°C (non-condensing)
Storage Temperature -10°C ~60°C @ 90% (non-condensing)
Vibration Loading During Operation With onboard eMMC
5Grms, IEC 60068-2-64, random, 5 ~ 500Hz, 1hr/axis
Shock During Operation With onboard eMMC
50G, IEC 60068-2-27, half size, 11ms duration
Dimensions 150mm (W) x 30mm (H) x 125.5mm (D) (5.91” x 1.18 ” x 4.94”)
Weight 0.566kg (1.25lbs)
Mounting VESA Mount (100mm x 100mm) (Optional)
Mechanical Construction Aluminum top cover
Metal chassis housing
Compliance CE/FCC
