Asus Q470EI-IM-A_R2-0 (Intel Core 10 Geração, socket LGA1200, s/ LVDS)
Asus Q470EI-IM-A_R2-0 (Intel Core 10 Geração, socket LGA1200, s/ LVDS)
Asus Q470EI-IM-A_R2-0 (Intel Core 10 Geração, socket LGA1200, s/ LVDS)
Asus Q470EI-IM-A_R2-0 (Intel Core 10 Geração, socket LGA1200, s/ LVDS)

Asus Q470EI-IM-A_R2-0 (Intel Core 10 Geração, socket LGA1200, s/ LVDS)

com IVA
301.35€

sem IVA
245.00€
Sku: Q470EI-IM-A_R2-0
Product Type: Boards Mini-ITX
Vendor: ASUS

Q470EI-IM-A_R2-0

Board Q470E mini-ITX, socket LGA1200 para processadores de 10ª geração sem LVDS
  • DDR4 2933MHz, 2 x SO-DIMM, each 32 GB
  • Supports 3 displays configuration by multiple interface: 2* DP/DVI-D/eDP
  • 7-year longevity supply
  • 1 x PCIe 3.0/2.0 x16
  • 3 x USB 3.2 Gen2 (2 x Type A, 1 x Type C)
  • 1 x M.2 socket 3 with M key, type 2242/2260/2280 (PCIe x4 and SATA mode)
  • 1 x M.2 socket 1 with E key, type 2230 for WIFI/BT device (PCIe and CNVi)
  • 5x COM
  • Power: ATX or 12V DC in (supported by our additional cable MBZ-1021)
Asus-iot
Caraterísticas

ASUS Q470EI-IM-A_R2-0 is a Mini-ITX industrial motherboard featuring rich I/O capabilities, advanced connectivity and flexible customization options in a smaller board that reduces chassis sizes for space-restrictive installations. Offering multiple display outputs, 2*DP, 1*DVI-D, and 1*eDP , legacy options for industrial applications, GPIO ports, dual Intel LAN as well as rich expandability with M.2 M key and M.2 E key, ASUS Q470EI-IM-A is an ideal choice for a wide range of embedded applications.

As the world’s No.1 motherboard brand, ASUS offers industrial motherboards with durable, industrial-grade components for reliable 24/7 operation in harsh environments and use in different vertical markets. ASUS provides a faster time-to-market with customization and motherboard modulation by leveraging over 30 years of design and innovation expertise, world-class after sales service, material supply flexibility, the ability to respond rapidly to forecast changes and long-term technical support, enabling customers to find the perfect solution to match their requirements.

Especificações

CPU: LGA1200 Socket for the 10th Gen. Intel® Core i9/i7/i5/i3/Pentium®/Celeron®

Chipset: Intel® Q470E Chipset

Memory: 2x SO-DIMM, max. 64GB, DDR4 2933 / 2666 / 2400 / 2133 MHz

Display: 2x DP, support DP 1.4 / 1x DVI-D

Expansion Slot: 1x PCIe 3.0 / 2.0 x16 Slot

1x M.2 Socket 1 with E key 2230

1x M.2 Socket 3 with M key 2242/2260/2280

Ethernet: Dual RJ45 (Intel® I210AT, 1x Intel® I219LM)

Audio: Realtek ALC887 High Definition Audio

Storage: 3x SATA Gen 3.0, up to 6Gb/s / 1x M.2 Socket 3 with M key

Downloads
Datasheet
