• Fanless AI Network video recorder platform
• 6-core NVIDIA Carmel ARM® v8.2 64-bit CPU 6MB L2 + 4MB L3 processor
• NVIDIA Volta™ architecture with 384 NVIDIA CUDA® cores
• Onboard 8 GB 128-bit LPDDR4x @ 1600 MHz51.2GB/s
• Supports 8 PoE ports
• Supports one HDMI display output
• Supports Ethernet x 9 ports (PoE x 8, GbE x 1)
• Supports ONVIF 2.0, 2MP IP camera up to 16 channels
• Supports AI functions
• CE, FCC, E-Mark, EN50155, MIL-STD-810G
| Model name | eNVP-JNX-IV-V0008 |
| Processor | 6-core NVIDIA Carmel ARM® v8.2 64-bit CPU 6MB L2 + 4MB L3 processor |
| Main Memory | Onboard 8 GB 128-bit LPDDR4x @ 1600 MHz 51.2GB/s |
| Format | H.265 / H.264 |
| Video Input | IP camera x 16 (PoE port x8) |
| Video Output | 1x HDMI 2.0 a/b maximum 3840 x 2160; VGA x 1 (optional) |
| Audio Input | RCA x1 |
| Audio Output | RCA x1 |
| Format | H.265 / H.264 |
| Resolution | 4K @ 60fps x 2 | 4K @ 30fps x 4 | 1080p @ 30fps x 16 |
| Internal HDD Bay | 1 x 2.5" SATA (removable) |
| RAID | NA |
| Ethernet | GbE port x1, PoE ports (10/100 MbE, total 75W): SKU1 x 8 PoE |
| WiFi | Optional |
| 4G / 5G | Optional |
| GPS / Gsensor | Onboard G-Sensor, GPS (optional) |
| Alarm Input | Alarm Input x 4 |
| Alarm Output | Alarm Output x 4 |
| Front I/O Panel | Power button x 1 IR receiver x 1 USB 2.0 x 1 GbE port x 1; PoE port x 8 Micro USB2.0 (Internal OTG) x 1 2.5“ SSD bay x 1 SIM card slot x 1 LED indicator x 2 (HDD, Fail) |
| Rear I/O Panel | Audio input x 1, Audio output x 1 USB 3.0 x 1, RS-232 x 1, RS485 x 1 HDMI x 1 Alarm IO (4-input, 4-output) x 1 Power input x 1 Antenna port x 5 |
| Expansion Slot | Mini PCIe x 2 (full-size USB2.0 x 1, half-size USB2.0 x 1) |
| Power Supply | DC 9 – 36V (with ignition pin) |
| Dimensions (W x D x H) | 175.6 x 183.3 x 50.5mm / 6.9“ x 7.2“ x 2“ (without bracket) |
| Gross Weight | 1.8kg / 4lb |
| Operating Temperature | -4°F ~149°F (-20°C ~+65°C) |
| Storage Temperature | -4°F ~185°F (-20°C ~+85°C) |
| Storage Humidity | 95% @ 40 °C (non-condensing) |
| Vibration/Shock | MIL-STD-810G |
| Certification | CE, FCC, E-Mark, EN50155, MIL-STD-810G |
