| Product name | 8" Resistive Touch Monitor |
| Model number / EAN number | FT08TMB / 6920734008117 |
| IP rating | IP40 |
| Screen diagonal (Inch/cm) | 8/20.32 |
| Display active screen size (cm) | 16.2×12.2 |
| Aspect ratio | 4:3 |
| Physical resolution | 1024×768 |
| Maximum showable resolution | 1920×1080 |
| Colours displayed | 16.7M |
| Brightness (cd/m²) | 250 |
| Contrast | 700:1 |
| Typical reaction time Tr/ Tf (ms) | 6/14 |
| Visual Angle horizontal/vertical (°) | 150/150 |
| Backlight / Backlight Lifetime (hours) | LED / 20,000 |
| Touch Technology | 4-Wire Resistive |
| Touch Panel Drivers | Windows; Linux; Mac; Android |
| Touch Life (Contacts) | 1 million touch in 1 location |
| Surface Hardness | 3H |
| Surface Treatment | Anti-glare |
| Operating Temperature (°C) | -25 ~ +75 |
| Humidity Range (RH) | 10% - 90% |
| Net weight (kg) | 0.80 |
| Gross weight (kg) | 2.05 (incl. cartonage) |
| Housing material | Plastic |
| Housing (cm) L × W × H | 19.80 × 16.80 × 3.61 |
| Mounting | VESA 75 |
| Power Indicator | Green LED |
| Power Supply | 100-240V ACDC active switching; 12V DC-Out |
| Working Power (V) | 8~36 |
| Power Consumption (W) | 6 |
| Stand-By Consumption (W) | <1 |
| Video | 1x HDMI 1.3 (incl. HDCP) |
| 1x VGA | |
| 1x Video1 | |
| 1x Video2_Backview | |
| 1x Backview-Detect | |
| 1x YpbPr | |
| Audio | 1x VGA-Audio |
| 1x Video-Audio | |
| 1x Earphone-Out | |
| Touch Connectors | 1x USB |
| 1x Serial | |
| Connectors | 1x 8~36V DC-IN |
| 1x USB (Front) |
| Power Supply (see Power section) |
| Short Installation Manual |
| Stylus |
| Remote Controller |
| Cables - VGA, USB Touch |
| Car Adapter |
| AV Molex 2.5 Connector |
| faytech FTV75PSF Stand |
| Mounting Frame |
| Mounting Rail |
| Cable Cover |
