| Product name | 10" Capacitive Touch Monitor |
| Article code / EAN number | FT10TMBCAPOB-V2 / 6920734010103 |
| IP65 Front / IP40 Back |
| Screen diagonal (Inch/cm) | 9.7/24.64 |
| Display active screen size (cm) | 19.7×14.7 |
| Aspect ratio | 4:3 |
| Physical resolution | 1024×768 |
| Maximum showable resolution | 1920×1080 |
| Colours displayed | 16.7M |
| Brightness (cd/m²) | 250 |
| Contrast | 800:1 |
| Typical reaction time Tr/ Tf (ms) | 10/15 |
| Visual Angle horizontal/vertical (°) | 170/170 |
| Backlight / Backlight Lifetime (hours) | LED / 20,000 |
| Touch Technology | Projected Capacitive 10-point Multitouch |
| Touch Panel Drivers | Windows; Linux; Mac; Android |
| Touch Life (Contacts) | Unlimited |
| Surface Hardness | 7H |
| Surface Treatment | Anti-glare (chemical etching) |
| Operating Temperature (°C) | -10 ~ +60 |
| Humidity Range (RH) | 10% - 90% |
| Net weight (kg) | 0.90 |
| Gross weight (kg) | 2.20 (incl. cartonage) |
| Housing material | Rubber front case, Plastic back case |
| Housing (mm) L × W × H | 244.9 × 195.8 × 39.0 |
| Cut-out for clamp supports (mm) L × H | 231.0 × 150.0 |
| Amount of clamps required | 4 |
| Mounting | VESA 75 |
| Power Indicator | Green LED |
| Power Supply | 100-240V ACDC active switching; 12V DC-Out |
| Working Power (V) | 12 |
| Power Consumption (W) | 8 |
| Stand-By Consumption (W) | <1 |
| Video | 1x HDMI 1.3 (incl. HDCP) |
| 1x DVI-D | |
| 1x VGA | |
| Audio | 1x PC-Audio |
| Touch Connector | 1x USB |
| Connectors | 1x 12V DC-In (screwable) |
| Power Supply (see Power section) |
| Short Installation Manual |
| Cables - VGA, USB Touch, Audio cable |
