Mini PC Android ultra-compacto fanless, suporte para os formatos de vídeo mais exigentes com resoluções de até 1080p. Saídas HDMI e VGA (opcionais). Scala Android Player, Scala Android HTML Player...

  • - Preços Sem IVA incluído.

  • - Valores sujeitos a alterações.

  • - Alguns dos valores requerem confirmação no acto da encomenda.

VIA Technologies
€188.00

Mini PC Android ultra-compacto fanless, suporte para os formatos de vídeo mais exigentes com resoluções de até 1080p. Saídas HDMI e VGA (opcionais). Scala Android Player, Scala Android HTML Player e Scala Android HTML Enhanced Player certificado, Android 4.0.3 BSP.



via-altads-datasheet

barebone-via-alta-ds

Model Name ALTA DS
Processor 800MHz VIA Cortex-A9 SoC
System Memory 1GB DDR3 SDRAM onboard
Storage 4GB eMMC Flash memory
Up to 16GB eMMC (optional)
Bootloader 512KB SPI Flash ROM onboard
Graphics Mali-400 SP GPU
2 integrated, independent 3D/2D graphics processing units
Graphics engine supporting OpenGL® ES 2.0 hardware acceleration
Supports MPEG-2, VC-1 and H.264 video decoding up to 1080p
LAN VIA VT6113 10/100 Base-TX PHY chip
Audio VT1603A I2S audio
Internal speaker (optional)
HDMI Integrated HDMI 1.4 transmitter
Front Panel I/O 2 USB 2.0 ports
1 SD card slot
2 Audio jacks: Line-out and Mic-in
1 Power on/off switch
Back Panel I/O 2 USB 2.0 ports (optional)
- 1 port for Wi-Fi
- 1 port for UART1 TX/RX
1 HDMI port
1 VGA port (optional)
1 10/100Mbps Ethernet port
1 DC-in jack
Power Supply 12V DC-in (typical: 3.35W)
Operating System Android 4.0.3, Linux kernel 3.0.8
Operating Temperature 0°C ~ 40°C
Operating Humidity 0 ~ 80% @ 40°C (non-condensing)
Storage Temperature -20°C ~ 70°C
Dimensions 175mm(W) x 25mm (H) x118(D) (6.88" x 0.98" x 4.64")
Weight 0.46kg (1.01lbs)
Compliance CE / FCC
