• Whiteboard interativo 86'
  • 8GB RAM / 128GB ROM
  • Resolução 4k 3840×2160
  • Vidro temperado
  • Android 13
com IVA
3,933.54€

sem IVA
3,198.00€
Sku: FT86A311D2OB
Product Type: Monitores Grande Formato
Vendor: Faytech

FT86A311D2OB

86" Interactive Whiteboard (Android 13)

  • Resolução 4K (3840 × 2160) e 1,07b cores exibidas
  • Android 13 OS com possibilidade de Windows 10/11 via OPS
  • 40 pontos de touch infravermelho e caneta (incluído)
  • True Living Optical para uma imagem de exibição mais vívida
  • Microfone e câmara perfeitos para meetings
  • Vidro temperado à prova de quebra
  • Montagem da VESA para facilitar a instalação ou suporte
  • Longa vida útil, construído para uso extensivo em escritórios e salas de aula
Caraterísticas
Interactive_Whiteboard
Especificações
Product Name 86" Interactive Whiteboard (Android 13)
Article Code FT86A311D2OB
Size 86 inch
Type a-Si TFT-LCD
Aspect Ratio 16:9
Backlight LED
Resolution 3840×2160
Refresh Rate 60Hz
Brightness 450nits
Contrast Ratio 4000:1
Viewing Angle (V/H) 178°/178°
Colors 1.07B (10 bits)
LED Lifetime ≥30,000H
Touch Area (L*W)/mm 1914*1088.6
Display Area (L*W)/mm 1897.04*1067.96
Glass Material AG (anti-glare chemical etching) tempered glass
Reflectivity <1%
Glass Thickness 3.2mm
Glass Hardness Mohs 7
Bonding True Optical bonding
Front 3x Public USB-A 3.0
  1x Touch USB-B 3.0 (for front HDMI 2.0)
  1x HDMI 2.0 in
  1x Type-C out (DP 1.2+Touch USB 2.0+PD 15W+100Mbps)
Rear 1x USB-C 3.0
  1x RS232 (DB9)
  1x Touch USB-B 3.0 (for DP in)
  1x DP 1.2A in
  1x HDMI 2.1 in
  1x HDMI 2.0 in (ARC)
  1x USB Type-C*1:
·Device mode: DP 1.2 in+Touch+PD 100W+USB 2.0, optional 100Mbps
·Host mode: USB 2.0
  1x Android USB-A 2.0
  1x Public USB-A 3.0
  1x OTG USB-A 2.0
  2x WiFi antenna (2.4GHz+5GHz, supports wifi6)
  1x Bluetooth 5.0
  1x Earphone out
  1x Coaxial or SPDIF out
  1x HDMI 2.1 out
  2x RJ45(10/100/1000Mpbs)
Version Android 13
CPU Amlogic A311D2
4x Cortex-A73 at 2.2GHz
4x Cortex-A53 at 2.0GHz
GPU Arm Mali-G52 MP8 (8EE)
RAM 8G LPDDR4
ROM 128G
Performance Technology: Infrared
Minimum Touch Object: 3mm
Touch Precision: 2mm
Writing Precision: ±0.5mm
Resolution: 32767x32767
Response Time: 3.3ms
Points 40 point touch/drawing, 20 point writing
Tools Fingers, pens, or other untransparent objects
Compatibility Windows XP/7/8/10/11; Linux; Chrome OS; Mac OS; Android
Features Dual color writing, palm as eraser
Light Resistance Works normally under 80,000 lux illumination (Full daylight ≈ 100,000 lux)
Physical Dimensions (L*W*T)/mm 1952.9*1155.1*88 (without wall mount)
1952.9*1155.1*114.2 (with wall mount)
Bezel Width/mm Top/Left/right:19.5
Bottom:47
Packed Dimensions (L*W*H)/mm 2154*230*1354
VESA mount installation position 800*600mm
Net Weight 66Kg±1Kg
Gross Weight 84Kg±1Kg
Speaker 2x 20W
Power (Type-C not included) AC:100-240V;60/50Hz;
550W(Max); 341.6W(Standard);
166.9W(ECO)≤0.5W(Standby)
Environmental Requirement Operation temperature: 0~40℃
Operation humidity: 20%~80%RH
In the Box 2x Pen
1x Remote control
1x 3M Power cable
1x 3M HDMI cable
1x 3M A-B USB cable
2x Manual (1 for All-in-one touch panel, 1 for wall mount)
1x Installation guide
1x Warranty card
1x Qualified certificate
1x Packing list
Wall Mount Standard included
Webcam Standard included
Mobile Floor Stand Optional
Warranty Touch panel/OPS & accessories: by sales contract.
Software upgrade: free for lifetime.
Model FTMP48 (with microphone)
Sensor 48MP Sensor for 12Mp Tetra Bayer with 1/2 optics in
Pipe Size 0.8x0.8u
Working Voltage 5V
Working Current 1A
Frequency 50Hz
Interface USB 2.0
Infrared Filter /
Lens Structure /
Interface Speed /
Video Format YUV / MJPG
Supported Resolutions 15fps@mjpg 4208X3120
30fps @mjpg/h264/h265 3840x2160 2560x1440 1920x1080
1280x720 1024x768 640x480 640x360 320x180
10fps@YUY2 1280x720
30fps@YUY2 640x480 320x240
Focus Mode Fixed focus
Focusing Speed /
Microphone 8MIC
MIC plate size 130x6mm
MIC spacing 40mm
Signal to Noise Ration (SNR) 64.5db
Sensitivity -26db
Acoustic Overload Point (AOP) 120 db SPL (Sound Pressure Level)
Pick-up Distance 10m
Indicator Yes
Algorithm Face Tracking, Sound Source Localization, echo cancellation
Field of View (FOV) D: 114.9 H: 110. V: 85.7 ±3°
Total Track Length (TTL) 7.18mm ± 0.15mm
Effective Focal Length (EFT) 2.59mm
F/NO (Infinite) 2.2 ± 5%
TV-distortion <1.5%
Focus Distance 0.4 - 10m
Effective Depth of Field 0.4 - 10m
Thread Specifications /
Sampling Ra /
Sampling Bits /
Wire FFC
Support Function 1. Acoustic Echo Cancellation (AEC)
2. 180° horizontal plane pickup, beamforming
3. Adaptive Environment Noise Reduction
4. Reverberation Removal
5. Sound Source Localization
6. Adaptive Voice Enhancement
7. Automatic Gain Control (AGC)
