The fanless Giada F302 Mini-PC, featuring an Intel® Core i3 6100U 2x 2,3 GHz Skylake CPU, a low-profile design, high performance, and quiet operation, is suitable for demanding digital signage requirements. The Giada F302 plays Ultra-HD video and can transmit data at high speed. Robust and ready for 24/7 operation.
Key features |
|
Applications |
|
Warranty |
|
Technical specifications |
|
| Product | Giada F302 |
| CPU | Intel® Core i3 6100U (6. Gen. Skylake) 2x 2,3 GHz |
| Graphics | Intel® HD520 Direct X12 |
| RAM | Barebone / up to 16GB (DDR III) |
| Storage | Barebone / 1x mSATA III / 1x M.2 / 1x SATA III SSD/HDD |
| Fan | - |
| Operating System | Windows 7 Windows 8 Windows 10 Linux |
| Power | Max. 20W |
|
I/O USB 2.0 USB 3.0 USB 3.0 (1x Type C) COM |
2x 3x 1x 6 x COM (4 x RS232, 2 x RS485) |
|
Ports HDMI 1.4 Display Port 1.2 VGA |
1x 1x 1x |
| Audio input/output | 1/1 |
|
Network LAN WLAN |
2x GB-LAN 802.11 a/b/g/n/ac (optional) |
| Expansion | 1x SIM 1x M.2 1x mSATA III 1x SATA III 1x Full-Size Mini PCIe (WiFi,3G,4G) |
| MTBF | 50.000 h |
| Operating temperature | 0°C ~ 40°C |
| Humidity | 5 ~ 90% non-condensing |
| Enclosure | Metal |
| Dimensions (HxWxD) | 175 x 260 x 35 mm |
| Weight | ca. 1500g |
