8' FT08TMB Resistive Touch Monitor
Price excludes VAT
249.00€
Sale price
Price excludes VAT
249.00€
Regular price
Total with VAT (23%): 306.27€
Shipping calculated at checkout.
FT08TMB
8' Resistive Touch Monitor
- Suitable for the most demanding industrial environments: ABS plastic housing, extended temperature range from -25 to 75 ° C, and protected cable.
- Driver support for all current operating systems.
- Suitable for wall mounting (mounting frame included).
- Extended 8-36V DC input voltage range.
- The most common audio and video connectors are available.
- High-resolution LCD panels.
- USB 2.0 connector on the front.
- Power supply included.
- 2-year warranty.
IP rating
Protection
IP40 front / IP40 rear
LCD Panel
Display Size
8"
Display Format
4:3
Physical Resolution
1024x768
Optical bonding
Air Gap
Coverglass
Operation / Mechanical
Housing
Backlight Type
Edge Backlight
Touch Panel
Touch Technology
Resistive
Coverglass Surface
Power
Power Supply
8-36V
External Connections
HDMI
1
VGA
1
DP
0
USB 2.0
1
USB 3.0
| Product name | 8" Resistive Touch Monitor |
| Model Number / EAN Number | FT08TMB / 6920734008117 |
| IP Rating | IP40 |
| Screen diagonal (inch/cm) | 8/20.32 |
| Active display area size (cm) | 16.2×12.2 |
| Aspect ratio | 4:3 |
| Physical resolution | 1024×768 |
| Maximum supported resolution | 1920×1080 |
| Displayed colours | 16.7M |
| Brightness (cd/m²) | 250 |
| Contrast | 700:1 |
| Typical response time Tr/ Tf (ms) | 6/14 |
| Horizontal/vertical viewing angle (°) | 150/150 |
| Backlight / Backlight lifetime (hours) | LED / 20,000 |
| Touch technology | 4-Wire Resistive |
| Touch panel drivers | Windows; Linux; Mac; Android |
| Touch life (contacts) | 1 million touches in 1 location |
| Surface hardness | 3H |
| Surface treatment | Anti-glare |
| Operating temperature (°C) | -25 ~ +75 |
| Humidity range (RH) | 10% - 90% |
| Net weight (kg) | 0.80 |
| Gross weight (kg) | 2.05 (incl. packaging) |
| Housing material | Plastic |
| Housing (cm) L × W × H | 19.80 × 16.80 × 3.61 |
| Mounting | VESA 75 |
| Power indicator | Green LED |
| Power supply | 100-240V ACDC active switching; 12V DC-Out |
| Operating voltage (V) | 8~36 |
| Power consumption (W) | 6 |
| Stand-By Consumption (W) | <1 |
| Video | 1x HDMI 1.3 (incl. HDCP) |
| 1x VGA | |
| 1x Video1 | |
| 1x Video2_Backview | |
| 1x Backview-Detect | |
| 1x YpbPr | |
| Audio | 1x VGA-Audio |
| 1x Video-Audio | |
| 1x Earphone-Out | |
| Touch Connectors | 1x USB |
| 1x Serial | |
| Connectors | 1x 8~36V DC-IN |
| 1x USB (Front) |
| Power supply (see Power section) |
| Quick installation manual |
| Stylus |
| Remote Controller |
| Cables - VGA, USB Touch |
| Car Adapter |
| AV Molex 2.5 Connector |
| faytech FTV75PSF Stand |
| Mounting Frame |
| Mounting Rail |
| Cable Cover |
