Panel PC 15.6' FT156N4200CAPOB (N4200, 4G/ 128GB)
Price excludes VAT
1,220.00€
Sale price
Price excludes VAT
1,220.00€
Regular price
Total with VAT (23%): 1,500.60€
Shipping calculated at checkout.
FT156N4200CAPOB
- Intel® Pentium® N4200 Quad Core
- 4 GB of RAM, 128 GB industrial SSD
- Windows 10 e Linux (32 bits, 64 bits)
- 1.1mm front glass with 7H hardness
- Anti-reflective surface treatment
- Touchscreen optically bonded to the LCD
- 10-point multi-touch capacitive touchscreen
- Patented IP65-rated front panel with silicone seal
- Speakers with audio amplifier
- Supports mounting clamps
- Integrated W-LAN
- 2-year warranty
| Product name | 15.6" Capacitive Touch PC |
| Article Code / EAN Number | FT156N4200CAPOB-V2 / 6920734001569 |
| CPU | Intel® Pentium® QuadCore N4200 |
| Graphics GPU | Intel® HD Graphics |
| Audio | Realtek ALC3236 audio CODEC |
| Memory | 4GB DDR3L non-ECC (max. 8GB) |
| Storage | faytech Industrial 128GB SSD |
| Network | 2x Realtek PCIe GB LAN 8111G (1x optional with POE); W-LAN |
| Driver Support | Win10; Linux; 32Bit/64Bit |
| Pre-installed OS | Linux Ubuntu |
| IP65 Front / IP40 Rear |
| Screen Diagonal (Inch/cm) | 15.6/39.6 |
| Active Screen Area Size (cm) | 34.42×19.36 |
| Aspect Ratio | 16:9 |
| Physical Resolution | 1920×1080 |
| Maximum External Resolution — HDMI, DP | 1920×1200 |
| Displayed Colours | 262K |
| Brightness (cd/m²) | 250 |
| Contrast | 800:1 |
| Typical Response Time Tr/ Tf (ms) | 15/15 |
| Horizontal/Vertical Viewing Angle (°) | 170/170 |
| Backlight / Backlight Lifetime (hours) | LED / min. 15,000 |
| Touch Technology | Projected Capacitive 10-point Multitouch |
| Touch Connector | USB |
| Touch Life (Contacts) | Unlimited |
| Surface Hardness | 7H |
| Surface Treatment | Antiglare (chemically etched) |
| Operating temperature (°C) | -10 ~ +60 |
| Humidity range (RH) | 10% - 90% |
| Net weight (kg) | 4.20 |
| Gross weight (kg) | 6.10 (incl. carton packaging) |
| Housing material | Rubber front case, aluminium IPC back case |
| Housing (mm) L × W × H | 389.3 × 246.8 × 49.3 |
| Cut-out for clamp supports (mm) L × H | 371.0 × 218.0 |
| Number of clamps required | 4 |
| Mounting | VESA 100 |
| Power indicator | Green LED |
| Power supply | 100-240V ACDC active switching; 12V DC output |
| Operating voltage (V) | 12 |
| Power consumption (W) | 16 |
| Stand-By Consumption (W) | <1 |
| 1x SO-DIMM, max. 8GB, DDR3L 1333/1600/1867 non-ECC, single-channel memory |
| 1x 12V DC power connector (2-pin) |
| 1x 4-pin SATA power connector |
| 1x Serial ATA 6Gb/s |
| 1x 5V/12V SATA power connector |
| 1x Front Panel box header |
| 1x LVDS box header |
| 1x SIM card header (connected to MiniPCIe) |
| 1x S/PDIF output pin header |
| 1x Line-out / Mic-in header |
| 1x DIO connector |
| 2x USB 3.0 box header |
| 1x 8-bit Digital I/O interface |
| 1x MIPI CSI connector |
| 3x RS232/RS485 switchable in BIOS |
| 2x LCD backlight control/LCD panel voltage box |
| 1x 12V DC-In (screwable) |
| 1x HDMI |
| 1x DisplayPort |
| 2x USB 3.0 ports |
| 2x USB 2.0 ports |
| 1x LVDS |
| 1x MIC-In & EAR-Out |
| 8x In/Out GPIO via RJ45 |
| 1x W-LAN antenna connector |
| 2x Full-PIN COM Ports - RS232/485; 5V/12V |
| 2x 3-PIN COM Ports - RX, TX, GND; RS232/485; 5V/12V |
| 2x 10/100/1000Mbit RJ45 Ports |
| 1x S/PDIF-Out (1x Cinch, 1x Torx module) |
| 1x 2.5" module slot, replaceable SSD included |
| 1x Mini PCIe + mSATA (with SIM card) - (2x Full Height/Half Height, changeable) |
| 1x PCIeX1 Straddle Connector |
| 1x M.2 E-key for wireless device |
| Power supply (see Power section) |
| W-LAN Antenna |
| Quick installation guide |
| Standard stand |
