Monitor 15.6' FT156TMCAPOB Capacitive Touch Optically bonded
Price excludes VAT
478.00€
Sale price
Price excludes VAT
478.00€
Regular price
Total with VAT (23%): 587.94€
Shipping calculated at checkout.
FT156TMBCAPOB-V2
15.6' Optically Bonded Capacitive Touch Monitor
- Anti-reflective surface treatment (chemical etching).
- 10-point capacitive multi-touch.
- 1,1 mm cover glass with 7H surface hardness.
- Touch panel optically bonded to the LCD panel.
- Patented IP65 front protection with silicone seal
- Integrated audio (2x2w)
- 2-year warranty
IP rating
Protection
IP65 front / IP40 rear
LCD panel
Display size
15,6"
Display format
16:9
Physical resolution
1920x1080
Brightness
300 cd/m²
Optical bonding
Optical bonding
Coverglass
1,1mm
Operation / Mechanical
Housing
Rubber frame
Backlight type
Edge backlight
Touch panel
Touch technology
Capacitive
Power
Power supply
12V
External connections
HDMI
1
VGA
1
DP
0
USB 2.0
0
USB 3.0
0
| Product name | 15.6" capacitive touch monitor |
| Article Code / EAN Number | FT156TMBCAPOB-V2 / 6920734016105 |
| IP65 front / IP40 rear |
| Screen diagonal (inch/cm) | 15.6/39.6 |
| Active display area size (cm) | 34.42×19.36 |
| Aspect ratio | 16:9 |
| Physical resolution | 1920×1080 |
| Maximum supported resolution | 1920×1080 |
| Displayed colours | 262K |
| Brightness (cd/m²) | 250 |
| Contrast | 800:1 |
| Typical response time Tr/ Tf (ms) | 15/15 |
| Horizontal/vertical viewing angle (°) | 170/170 |
| Backlight / Backlight lifetime (hours) | LED / min. 15,000 |
| Touch technology | Projected capacitive 10-point multitouch |
| Touch panel drivers | Windows; Linux; Mac; Android |
| Touch life (contacts) | Unlimited |
| Surface hardness | 7H |
| Surface treatment | Anti-glare (chemical etching) |
| Operating temperature (°C) | -10 ~ +60 |
| Humidity range (RH) | 10% - 90% |
| Net weight (kg) | 3.40 |
| Gross weight (kg) | 5.30 (incl. packaging) |
| Housing material | Rubber front, plastic ABS rear housing |
| Housing (mm) L × W × H | 389.3 × 246.8 × 33.3 |
| Cut-out for clamp supports (mm) L × H | 371.0 × 218.0 |
| Number of clamps required | 4 |
| Mounting | VESA 100 |
| Power indicator | Green LED |
| Power supply | 100-240V ACDC active switching power supply; 12V DC-Out |
| Operating voltage (V) | 12 |
| Power consumption (W) | 13 |
| Standby power consumption (W) | <1 |
| Video | 1x HDMI 1.3 (incl. HDCP) |
| 1x DVI-D | |
| 1x VGA | |
| Audio | 1x PC-Audio |
| Touch connector | 1x USB |
| Connectors | 1x 12V DC-In (screw-locking) |
| Power supply (see Power section) |
| Quick installation guide |
| Cables - VGA, USB Touch, audio cable |
| Standard stand |
