Panel PC 8' HPC080SC-FP2807A (N2807, 2G)
-
8" high-brightness TFT display with LED backlighting.
-
10-point capacitive multi-touchscreen.
-
2GB RAM, 32GB SSD.
-
Highly efficient fanless operation.
-
Durable aluminium construction.
-
Designed for easy wall, panel or VESA mounting.
-
Flat, easy-to-clean front surface with an edge-to-edge design.
Specifications:
|
Display |
|
|
Front Bezel |
– IP65, NEMA 4 rugged protection, full planar metal bezel |
|
Display Type |
– 8″ display with LED backlighting |
|
Brightness (cd/m²) |
– 400 nits |
|
Display Colors |
– 16.7M |
|
Resolution |
– 1024 x 768 @ 60Hz |
|
Viewing Angle (H/V) |
– 160°/160° |
|
Pixel Pitch |
– 0.158 x 0.158 mm |
|
Aspect ratio |
– 4:3 |
|
Contrast Ratio |
– 700:1 |
|
Response Time |
– 30 ms |
|
Touch Screen |
|
|
Type |
– Projected capacitive type |
|
Active Range |
– 163.05 x 122.54mm ±0.2mm |
|
Transparency |
– ≧85% |
|
Surface Hardness |
– ≧6H (JIS-5400) |
|
Glass Haze Value |
– ≦ 3% |
|
CASE |
|
|
Panel Material |
– Aluminium |
|
Case Material |
– Iron |
|
Color |
– Silver + white |
|
Coating requirement |
– Spray paint |
|
Main system |
|
|
CPU |
– Intel® Bay Trail-M N2807 1.58GHz/DC |
|
RAM |
– 2G 1333MHz DDR3L SAMSUNG DRAM |
|
BIOS |
– 64MB SPI Flash ROM |
|
Storage |
– 1 * mSATA connector (full size) |
|
Watchdog timer |
– 256 levels, 0~255 sec. |
|
OS Support |
– Windows 7 / 8.1 / 10 / Linux (optional) |
|
I/O connector |
|
|
I/O ports and switches |
– 1 * USB3.0 |
|
Expansion interface |
|
|
Expansion |
– 1 * PCI-E mini card for Wi-Fi or 3G/4G |
|
Power |
|
|
Power input |
– Supports 12V DC power input with an overcurrent protection fuse |
|
Power consumption |
– 13W |
|
Dimensions |
|
|
Case dimensions |
– 191.05 * 150.54 * 57.70mm |
|
Certifications |
|
|
Certifications |
– CE, FCC, IP65 (front) |
|
Environment |
|
|
Temperature |
– Operating temperature: -10 ~ 60° C (with W.T. DRAM/HDD under airflow conditions) |
|
Shock |
– Operating: 15G, 11ms duration |
|
Vibration |
– Operating: 5~500Hz/1 Grms |
|
Warranty |
|
|
Warranty |
– 2-year limited warranty (panel and touch screen have only a 1-year warranty) |
* Specifications are subject to change without notice. We are not responsible for typographical errors. HDD and OS are not included.
