Monitor 15.6' FT156TMIP65HB Capacitive Touch IP65
Price excludes VAT
1,028.88€
Sale price
Price excludes VAT
1,028.88€
Regular price
Total with VAT (23%): 1,265.52€
Shipping calculated at checkout.
FT156TMIP65HB
15.6' IP65 Capacitive Touch Monitor
- Complete IP65 chassis protection
- Chassis material: stainless steel
- Operating temperature: -20 °C to 70 °C
- Cover glass surface treatment: anti-reflective (chemical etching)
- 10-point projected capacitive multi-touch
- Glass thickness: 2 mm
- Touch panel optically bonded to the LC panel
- 2-year warranty
| Characteristic | Details | |
| Product details | Product name | 15.6" IP65 Capacitive Touch Monitor |
| Article Code / EAN | FT156TMIP65HB / 6920734003624 | |
| Screen (Display) | Size [inches] | 15.6 |
| Aspect ratio | 16 : 9 | |
| Resolution | 1920 × 1080 | |
| Active area [mm] | 344.16 × 193.59 | |
| Brightness [cd/m²] | 1000 | |
| Contrast ratio | 800 : 1 | |
| LED Service Life [h] | 100.000 | |
| Viewing angle [°] | 170 / 170 | |
| Display interface | LVDS | |
| PC System | Monitor controller | Realtek® RTD2556T |
| Speakers | 2× 1,5W | |
| Video Inputs | 1x HDMI, 1x DP, 1x VGA | |
| Other Connections | 1x Audio In, 1x USB Touch, 1x RS232 Serial Port | |
| Light sensor | 1 | |
| Touch panel | Touch type | Projected Capacitive, 10-point Multi-touch |
| Glass Thickness [mm] | 2.0 | |
| Surface Treatment | AG (Chemical Etching — Anti-Glare) | |
| Impact Protection | IK08 | |
| Glass Strengthening | Thermally Strengthened | |
| Touch Controller | EXC81W84 | |
| Optical Bonding | Clear Bond® | |
| Environmental Conditions | Operating Temp. | -20°C to 70°C |
| Storage Temp. | -20°C to 70°C | |
| Humidity Range | 10% to 90% | |
| Certifications | Certified | CE and FCC |
| Chassis | Enclosure design | SS-IP65 |
| IP protection | Full-front IP65 protection | |
| Material | Brushed stainless steel (silver) | |
| Dimensions (C×L×A) [mm] | 384.2 × 242.2 × 60.0 | |
| Mounting | VESA 100 × 100 | |
| Power | Operating voltage | 9-36V |
| Power consumption | 12W (on) / <1W (standby) | |
| Accessories | Included | Power adapter (12V DC-Out), USB-Touch cable and quick-start manual |
| Weight and packaging | Net weight | ~3.80 kg |
| Gross weight | ~4.60 kg | |
| Packaging material | 100% recyclable cardboard and polyethylene (PE) |
