Monitor 15.6' FT156TMIP69KHB Capacitive Touch IP69K
Price excludes VAT
1,058.88€
Sale price
Price excludes VAT
1,058.88€
Regular price
Total with VAT (23%): 1,302.42€
Shipping calculated at checkout.
FT156TMIP69KHB
15.6' IP69K capacitive touch monitor
- Full IP65/IP69K chassis protection
- Chassis material: stainless steel
- Operating temperature: -20 °C to 70 °C
- Cover glass surface treatment: anti-reflective (chemical etching)
- 10-point projected capacitive multi-touch
- Glass thickness: 2 mm
- Touch panel with optical bonding and LC panel
- 2-year warranty
| Characteristic | Details | |
| Product details | Product name | 15.6" IP69K capacitive touch monitor |
| Item code / EAN | FT156TMIP69KHB / 6920734003679 | |
| Screen (Display) | Size [inches] | 15.6 |
| Aspect ratio | 16 : 9 | |
| Resolution | 1920 × 1080 | |
| Active area [mm] | 344.16 × 193.59 | |
| Brightness [cd/m²] | 1000 | |
| Contrast ratio | 800 : 1 | |
| LED service life [h] | 100.000 | |
| Viewing angle [°] | 170 / 170 | |
| Display interface | LVDS | |
| PC system | Monitor controller | Realtek® RTD2556T |
| Speakers | 2× 2W | |
| M12 connector (12 pins) | 1x IP69K 9-36V | |
| HDMI connector | 1x IP69K | |
| Light sensor | 1 | |
| Touch panel | Touch type | Projected capacitive, 10-point multi-touch |
| Printing type | Ceramic | |
| Glass thickness [mm] | 2.0 | |
| Surface treatment | AG (chemical etching — anti-glare) | |
| Impact protection | IK08 | |
| Print colour | RAL9004 (black) | |
| Glass strengthening | Thermally strengthened | |
| Touch controller | EXC81W84 | |
| Touch interface | USB | |
| Touch resolution | RX39 / TX24 | |
| Optical bonding | Clear Bond® | |
| Environmental conditions | Operating temp. | -20°C to 70°C |
| Storage temp. | -20°C to 70°C | |
| Humidity range | 10% to 90% | |
| Certifications | CE / FCC certification | Yes / Yes |
| Chassis | Enclosure design | SS-IP69K |
| IP protection | Full IP69K protection | |
| Colour / material | Silver / brushed stainless steel | |
| Dimensions (L×W×H) [mm] | 384.2 × 242.2 × 60.0 | |
| Mounting | VESA 100 × 100 | |
| Power | Power indicator | Green LED |
| Operating voltage | 9-36V | |
| Power consumption | 12W (on) / <1W (standby) | |
| Accessories | Included cables | Adapter, IP69K DC-In/Touch/COM cable and IP69K HDMI cable |
| Manual | Quick-start instruction manual included | |
| Weight and packaging | Net weight | ~3.80 kg |
| Gross weight | ~4.60 kg (including box) | |
| Packaging material | 100% recyclable cardboard and polyethylene (PE) |
