Compact industrial edge AI platform powered by NVIDIA® Jetson Orin Nano™ in 4 GB or 8 GB Super Mode configurations, designed for multi-camera vision, precise positioning, and industrial communications.
Key features
- Two configurations with 34 or 67 TOPS
- Built-in 128 GB NVMe and M.2 B/E/M-Key expansion
- Dual GbE and 120-pin MIPI expansion connector
- USB 3.2 Gen 2, CAN FD, RS-232 and RS-422/485
- Optional OOB and GPS 1PPS through M.2 B-Key
- 12–24 VDC input; -25°C to +80°C operation
Overview
Unlock Superior Vision AI with Super Mode for NVIDIA Jetson Orin Nano
Designed for sensor fusion, precise positioning, and real-time transmission.
The AIB-MO22/32-S2 enables Super Mode for NVIDIA Jetson Orin Nano through JetPack 6.2, delivering increased generative AI performance and memory bandwidth for demanding Vision AI and GenAI workloads.
Available configurations:
- AIB-MO22-1-S2: Jetson Orin Nano 4 GB, 34 TOPS.
- AIB-MO32-1-S2: Jetson Orin Nano 8 GB, 67 TOPS.
Configurations
| Model | Module | Memory | Performance |
|---|---|---|---|
| AIB-MO22-1-S2 | Jetson Orin Nano | 4 GB | 34 TOPS |
| AIB-MO32-1-S2 | Jetson Orin Nano | 8 GB | 67 TOPS |
Product Benefits
| Product Benefit | Description |
|---|---|
| Accelerated GenAI Performance, Lower TCO | Super Mode increases AI compute by up to 70%, memory bandwidth by up to 50%, and generative AI model performance by up to 2×. |
| Vision, Connectivity and Positioning | GMSL and MIPI camera support through the 120-pin connector, M.2 B-Key for 4G/5G/LTE and GPS 1PPS, M.2 E-Key for Wi-Fi/Bluetooth, and dual GbE. |
| Integrated Peripherals | Validated cameras and wireless peripherals shorten development time and accelerate AI adoption. |
| OOB and TPM 2.0 | Optional OOB management through Aetina EdgeEye and hardware-based security with TPM 2.0. |
| Edge-Ready Industrial Design | Compact form factor, 12–24 VDC input, and -25°C to +80°C operating temperature. |
| NVIDIA JetPack™ 6.2 | Supports NVIDIA JetPack™ 6.2 and above. |
| Long-Term Product Longevity | Planned five-year lifecycle backed by Aetina technical and engineering support. |
| Targeted Applications | Smart cities, security, retail, logistics robots and AMRs, precision agriculture, manufacturing, automation, and autonomous robotics. |
Sistema
| Modelos | AIB-MO22-1-S2 / AIB-MO32-1-S2 |
|---|---|
| Módulo | NVIDIA Jetson Orin Nano 4/8 GB com Super Mode |
| Desempenho AI | 34 / 67 TOPS |
| Memória | 4 / 8 GB LPDDR5 |
| Armazenamento | 1x M.2 M-Key 2242, NVMe 128 GB integrado |
| Vídeo | 1x HDMI 1.4 Type-A |
Interfaces e expansão
| Rede | 2x RJ-45 GbE |
|---|---|
| Câmara | Conector MIPI de 120 pinos; suporte MIPI/GMSL com drivers validados |
| USB | 2x USB 3.2 Gen 2, 1x USB-C OTG |
| Expansão | M.2 B-Key, E-Key e M-Key; micro SIM |
| I/O | GPIO, SPI, I²S, I²C, UART, RS-232, CAN FD isolado e RS-422/485 |
Ambiente e mecânica
| Alimentação | 12–24 VDC |
|---|---|
| Temperatura | -25 °C a +80 °C; armazenamento -40 °C a +85 °C |
| Dimensões | 120 × 100 × 36,56 mm sem dissipador; 120 × 100 × 77,41 mm com dissipador |
| Software | Linux; NVIDIA JetPack 6.2 ou superior |
| Funções | TPM 2.0, RTC e OOB opcional |
