7 'FT07TMB Resistive Touch Monitor
Price excludes VAT
229.00€
Sale price
Price excludes VAT
229.00€
Regular price
Total with VAT (23%): 281.67€
Shipping calculated at checkout.
FT07TMB
7' Resistive Touch Monitor
- Suitable for the most demanding industrial environments: ABS plastic enclosure, extended temperature range from -25 to 75 ° C, and protected cable
- Drivers for all current operating systems
- Suitable for wall mounting (mounting bracket included)
- Wide-range 8-36V DC voltage input
- The most common audio and video connectors are available
- High-resolution LCD panels
- Front USB 2.0 connector
- Power supply included
- 2-year warranty
IP rating
Protection
IP40 front / IP40 rear
LCD Panel
Display Size
7"
Display Format
16:10
Physical Resolution
1024x600
Optical bonding
Air Gap
Operation / Mechanical
Backlight Type
Edge Backlight
Touch Panel
Touch Technology
resistive
Power
Power Supply
8-36V
External Connections
HDMI
1
VGA
1
DP
0
USB 2.0
1
USB 3.0
0
| Product name | 7" Resistive Touch Monitor |
| Model number / EAN number | FT07TMB / 6920734007110 |
| IP Rating | IP40 |
| Screen diagonal (inch/cm) | 7/17.78 |
| Active display area size (cm) | 15.36×9.00 |
| Aspect ratio | 16:9 |
| Physical resolution | 1024×600 |
| Maximum supported resolution | 1920×1080 |
| Displayed colours | 262K |
| Brightness (cd/m²) | 500 |
| Contrast | 700:1 |
| Typical response time Tr/ Tf (ms) | 10/15 |
| Horizontal/vertical viewing angle (°) | 150/145 |
| Backlight / Backlight lifetime (hours) | LED / 20,000 |
| Touch technology | 4-Wire Resistive |
| Touch panel drivers | Windows; Linux; Mac; Android |
| Touch life (contacts) | 1 million touches in 1 location |
| Surface hardness | 3H |
| Surface treatment | Anti-glare |
| Operating temperature (°C) | -25 ~ +75 |
| Humidity range (RH) | 10% - 90% |
| Net weight (kg) | 0.60 |
| Gross weight (kg) | 1.80 (incl. packaging) |
| Housing material | Plastic |
| Housing (cm) L × W × H | 17.90 × 12.30 × 3.20 |
| Mounting | VESA 75 |
| Power indicator | Green LED |
| Power supply | 100-240V ACDC active switching; 12V DC-Out |
| Operating voltage (V) | 8~36 |
| Power consumption (W) | 7 |
| Stand-By Consumption (W) | <1 |
| Video | 1x HDMI 1.3 (incl. HDCP) |
| 1x VGA | |
| 1x Video1 | |
| 1x Video2_Backview | |
| 1x Backview-Detect | |
| 1x YpbPr | |
| Audio | 1x VGA-Audio |
| 1x Video-Audio | |
| 1x Earphone-Out | |
| Touch Connectors | 1x USB |
| 1x Serial | |
| Connectors | 1x 8~36V DC-IN |
| 1x USB (Front) |
| Power supply (see Power section) |
| Quick installation manual |
| Stylus |
| Remote Controller |
| Cables - VGA, USB Touch |
| Car Adapter |
| AV Molex 2.5 Connector |
| faytech FTV75PSF Stand |
| Mounting Frame |
| Mounting Rail |
| Cable Cover |
