Switch LNX-1002G-SFP-T (8* 10/100/1000Tx + 2* 100/1000 SFP)
LNX-1002G-SFP-T
Antaira’s LNX-1002G-SFP-T industrial Gigabit unmanaged Ethernet switch series is IP30 rated and DIN-Rail mountable. Each unit is designed with 8 Gigabit Ethernet ports and 2 dual-rate (100/1000) SFP slots, making it ideal for applications that demand high bandwidth and long-distance communication. This product series provides high EFT and ESD protection against unregulated voltage and is suitable for harsh environments. It supports power redundancy through a dual power input design with reverse polarity protection. In addition, the built-in relay warning function alerts maintenance personnel when power failures occur.
The LNX-1002G-SFP-T has an extended operating temperature range of -40 to 75°C and is designed to meet the specific requirements of industrial automation, outdoor applications and harsh weather environments.
- Supports 8-Port 10/100/1000Tx + 2-Port 100/1000 SFP
- Supports Auto MDI/MDI-X Function
- Store-and-Forward Switching Architecture
- 20Gbps Backplane (Switching Fabric)
- 8K MAC address table
- 9.6Kbytes Jumbo Frame support
- Surge protection: 2,000 VDC support
- ESD protection: 6,000 VDC support
- Redundant power input design: 12~48VDC
- Built-in 1 relay output for power failure detection
- IP30 rugged metal enclosure design
- DIN-rail and wall-mount support
- Operating Temperature Range - STD: -40° to 75° C
- 5-Year Warranty
