Switch LNX-1204G-SFP-T (8* 10/100/1000Tx + 4* 100/1000 SFP)
LNX-1204G-SFP-T
Antaira’s new LNX-1204G-SFP-T industrial Gigabit unmanaged Ethernet switch is IP30 rated and DIN-rail mountable. The unit features 8 Gigabit Ethernet ports and 4 dual-rate (100/1000) SFP slots for fiber connections, making it ideal for applications that require high bandwidth and long-distance communication.
This product provides high EFT and ESD protection against unregulated voltage and is suitable for harsh environments. It also supports an extended operating temperature range from -40 to 75°C.
The LNX-1204G-SFP-T is an ideal industrial networking product for applications that require high-bandwidth or high-density connections, such as power/utilities, water and wastewater treatment, oil/gas/mining, process control automation, security access control systems, and intelligent transportation systems.
- Supports 8*10/100/1000Tx + 4*100/1000 SFP ports
- Supports Auto MDI/MDI-X Function
- Store-and-Forward Switching Architecture
- 24Gbps backplane (switching fabric)
- 8K MAC address table
- 9.6Kbytes Jumbo Frame support
- Surge protection: 2,000 VDC support
- ESD protection: 6,000 VDC support
- Redundant power input design: 12~48VDC
- Built-in 1 relay output for power failure detection
- IP30 rugged metal enclosure design
- DIN-rail and wall-mount support
- Operating temperature range: -40° to 75° C
- 5-Year Warranty
