Neousys Nuvo-7162GC (Intel Core 9/ 8ª Gen, NVIDIA Quadro P2200)
Nuvo-7162GC
Ruggedized GPU computing platform supporting NVIDIA® Quadro P2200 and Intel® 9th/8th-Gen Core™ processor
- Supports NVIDIA® Quadro P2200 GPU
- Wide-temperature operation from -25°C to 60°C, with no GPU throttling up to 54°C
- Intel® 9th/ 8th-Gen Core™ hexa-core 35W/ 65W LGA1151 CPU
- 6x GigE ports, with an 802.3at PoE+ option available (ports 3~6)
- M.2 2280 M key NVMe (Gen3 x4) socket for fast storage access
- 4x USB 3.1 Gen2 ports and 4x USB 3.1 Gen1 ports
- Accommodates two 2.5" SATA HDD/SSDs with RAID 0/1 support
- MezIO™ interface for easy function expansion
Nuvo-7162GC series systems are ruggedized AI inference platforms supporting an NVIDIA® Quadro P2200, which provides a longer product life cycle for industrial AI inference applications such as machine vision, automation and video analytics. Powered by the NVIDIA® Quadro P2200, Nuvo-7162GC delivers 3.8 TFLOPS of GPU computing power for real-time inference. In addition, it provides a 50% CPU performance improvement over the previous generation.
Thanks to Neousys' patented Cassette and innovative ventilation mechanism, the system fan directs cool ambient air directly onto the GPU card fan, significantly improving heat-dissipation efficiency for the Quadro P2200. This cooling design guarantees non-throttling GPU performance up to 54°C and an operating temperature of up to 60°C for the entire system.
Nuvo-7162GC series systems feature a wide range of advanced I/O functions. An M.2 NVMe interface provides fast storage access with read/write speeds exceeding 2000 MB/s. The systems also include 6x GbE ports and 8x USB3.1 ports for image data acquisition. In addition, they support the MezIO interface for I/O expansion.
By supporting the Quadro P2200, Nuvo-7162GC series systems provide superior system longevity, so users need not worry about frequent GPU generation changes. Nuvo-7162GC is the ideal ruggedized inference platform for industrial Edge AI applications.
■ NEOUSYS MARKETING TEAM
| System Core | |
|---|---|
| Processor | Supports Intel® 9th/ 8th Gen Core™ CPU (LGA1151 socket, 65W/35W TDP) - Intel® Core™ i7-9700E/ i7-9700TE/ i7-8700/ i7-8700T - Intel® Core™ i5-9500E/ i5-9500TE/ i5-8500/ i5-8500T - Intel® Core™ i3-9100E/ i3-9100TE/ i3-8100/ i3-8100T |
| Chipset | Intel® Q370 Platform Controller Hub |
| Graphics | Integrated Intel® UHD Graphics 630 |
| Memory | Up to 64 GB DDR4 2666/ 2400 SDRAM (two SODIMM slots) |
| AMT | Supports AMT 12.0 |
| TPM | Supports TPM 2.0 |
| I/O Interface | |
|---|---|
| Ethernet Port | 6x Gigabit Ethernet ports via 1x I219 and 5x I210 |
| POE+ | Optional IEEE 802.3at PoE+ PSE for ports 3 ~ 6, with a 100 W total power budget |
| USB | 4x USB 3.1 Gen2 ports (10 Gbps) 4x USB 3.1 Gen1 ports (5 Gbps) |
| Video Port | 1x VGA connector, supporting 1920 x 1200 resolution 1x DVI-D connector, supporting 1920 x 1200 resolution 1x DisplayPort connector, supporting 4096 x 2304 resolution |
| Serial Port | 2x software-programmable RS-232/422/485 ports (COM1/ COM2) 2x RS-232 ports (COM3/ COM4) |
| Audio | 1x 3.5 mm jack for mic-in and speaker-out |
| Internal Expansion Bus | |
|---|---|
| PCI/PCI Express | 1x PCIe x16 slot@Gen3, 16-lanes PCIe signal in the Cassette for installing a Quadro P2200 GPU |
| Mini PCI-E | 1x full-size mini PCI Express socket with internal SIM socket (mux with mSATA) |
| M.2 | 1x M.2 2242 B key socket with dual front-accessible SIM sockets, supporting dual SIM mode with a selected M.2 LTE module |
| Expandable I/O | 1x MezIO™ expansion port for Neousys MezIO™ modules |
| Storage Interface | |
|---|---|
| SATA HDD | 2x internal SATA ports for 2.5" HDD/SSD installation, supporting RAID 0/ 1 |
| M.2 | 1x M.2 2280 M key socket (PCIe Gen3/ x4) for NVMe SSD or Intel® Optane™ memory installation |
| mSATA | 1x full-size mSATA port (mux with mini-PCIe) |
| Power Supply | |
|---|---|
| DC Input | 1x 3-pin pluggable terminal block for 8V to 35V DC input |
| Remote Control & LED Output | 1x 3-pin pluggable terminal block for remote control and PWR LED output |
| Mechanical | |
|---|---|
| Dimensions | 240 mm (W) x 225 mm (D) x 111 mm (H) |
| Weight | 4.5 Kg |
| Mounting | Wall-mount mounting bracket |
| Environmental | |
|---|---|
| Operating temperature | With 35W CPU and Quadro P2200 -25°C ~ 60°C ** With 65W CPU and Quadro P2200 -25°C ~ 60°C */** (configured for 35W TDP) -25°C ~ 50°C */** (configured for 65W TDP) |
| Storage temperature | -40°C ~ 85°C |
| Humidity | 10% ~ 90%, non-condensing |
| Vibration | Operating, MIL-STD-810G, Method 514.6, Category 4 |
| Shock | Operating, MIL-STD-810G, Method 516.6, Procedure I, Table 516.6-II |
| EMC | CE/FCC Class A, according to EN 55032 & EN 55024 |
* For i7-9700E and i7-8700 operating in 65W mode, the maximum operating temperature must be limited to 50°C, and thermal throttling may occur under sustained full load. Users can configure CPU power in BIOS to achieve a higher operating temperature.
** For operation at sub-zero temperatures, a wide-temperature HDD or Solid State Disk (SSD) is required.
Optional IEEE 802.3at PoE+ for GbE ports 3 ~ 6
Supported MezIO™ Modules
The Neousys MezIO™ module provides computer signals, power rails, and control signals through a high-speed connector. It transforms Neousys embedded systems into application-specific systems with application-oriented I/Os such as RS-232/422/485, isolated DIO, and ignition power control.
(Click here for details of compatible MezIO™ modules)
Accessories
PA-280W-OW
280W AC/DC power adapter, 24V/11.67A; 16AWG/100cm; cord-end terminals for terminal block; operating temperature: -30°C to 60°C.
Damping bracket
Neousys' patented damping bracket assembly for Nuvo-7162GC
