Sku: POC-551VTC
Product Type: PCs In-Vehicle
Vendor: Neousys

POC-551VTC

AMD Ryzen™ V1605B ultra-compact In-vehicle controller with PoE+, DIO and isolated CAN bus

  • AMD Ryzen™ embedded V1605B quad-core 15W CPU
  • -40°C to 70°C rugged wide temperature fanless operation
  • Four IEEE 802.3at PoE+ ports with screw-lock
  • One isolated CAN bus port for in-vehicle communication
  • One M.2 socket and three mPCIe sockets
  • M.2 2280 M key NVMe (Gen3 x2) socket for fast storage access
  • 4-CH isolated DI and 4-CH isolated DO
  • 8~35V DC input with built-in ignition power control
  • E-Mark(E13 No. 10R-0615611) and EN 50155/ EN 45545 certificate
Vista Rápida

POC-551VTC is the next generation ultra-compact, fanless in-vehicle controller offering performances never-seen-before in this form factor.

Featuring AMD Ryzen™ Embedded V1000 4-core/ 8-thread processor(V1605B), POC-551VTC delivers up to 3x times the CPU performance compared to previous POC series. It combines finesse performance, extraordinary reliability and affordability for versatile in-vehicle applications.

POC-551VTC offers four 802.3at PoE+ ports to supply 25W power to device such as IP cameras. As wireless connectivity is essential for modern invehicle application, POC-551VTC with built-in one M.2 and three mini-PCIe are more applicable for in-vehicle use nowadays. It also integrates CAN bus for in-vehicle communication, and isolated DIO for sensor/ actuator control.

Combining ignition power control and wide-range DC input along with superior performance, POC-551VTC can provides perfect solution for all your in-vehicle application needs in an extremely compact size!

■ NEOUSYS MARKETING TEAM

Especificações
System Core
Processor AMD Ryzen™ V1605B CPU
( 4C/ 8T, 2M Cache, 2.0/ 3.6 GHz, 12W - 25W TDP)
Graphics Vega GPU with 6 compute units
Memory Up to 16 GB DDR4-2400 SDRAM by one SODIMM sockets
TPM Supports TPM 2.0
Panel I/O Interface
Ethernet 4x Gigabit Ethernet ports by Intel® I350-AM4 controller
POE 4xIEEE 802.3at Gigabit PoE+ ports by Intel® I350-AM4
CAN Bus 1x CAN 2.0 port
Isolated DIO 4x Isolated DI and 4x Isolated DO
USB 4x USB 3.1 Gen1 ports with screw-lock
Video Port 1x VGA connector, supporting 1920 x 1200 resolution
1x DisplayPort connector, supporting 4096 x 2160 resolution
Serial Port 1x software-programmable RS-232/ 422/ 485 ports (COM1)
3x 3-wire RS-232 ports (COM2/ 3/ 4) or 1x RS-422/ 485 port(COM2)
Audio 1x 3.5 mm jack for mic-in and speaker-out
Storage Interface
M.2 1x M.2 2280 M key NVMe socket (PCIe Gen3/ x2) installation
mSATA 1x full-size mSATA port
Expansion Bus
Mini PCIe 3x full-size mini PCI Express socket with internal SIM socket
M.2 1x M.2 2242 B key socket for 3G/ 4G option with USIM support
Power Supply
DC Input 1x 3-pin pluggable terminal block for 8V to 35V DC input
Remote Ctrl.& LED Output 1x3-pin pluggable terminal block for remote control and PWR LED output
Mechanical
Dimension 64 mm (W) x 116 mm (D) x 176 mm (H)
Weight 1.3 kg
Mounting Wall-mount (standard) or DIN-rail mount (optional)
Environmental
Operating Temperature -40°C ~ 70°C*
Storage Temperature -40°C ~85°C
Humidity 10%~90% , non-condensing
Vibration IEC61373:2010, Category 1, Class B Body mounted (part of EN50155)
Shock IEC61373:2010, Category 1, Class B Body mounted (part of EN50155)
EMC EN 50155, EN45545, E-Mark for in-vehicle applications
CE/FCC Class A, according to EN 55032 & EN 55024
■ Date last revised: Oct. 14, 2019

* For sub-zero and over 60°C operating temperature, a wide temperature HDD or Solid State Disk (SSD) is required.
