IoT Router UR75-500GL-G-W (5G, WiFi, 5*GLAN, 232/485, DI/DO, GPS)
UR75-500GL-G-W
Milesight UR75 5G Industrial Cellular Router
Built on a high-performance industrial platform with a quad-core CPU and cellular module, the UR75 delivers wire-speed networking in an ultra-compact form factor, ensuring an extremely secure and reliable wireless network connection.
Equipped with the latest cellular technology, 5G, the UR75 provides ultra-fast broadband access over a 5G cellular network.
The UR75 also features a 5-port Gigabit Ethernet switch, serial ports (RS232/RS485), and DI/DO (Digital Input/Digital Output), enabling M2M applications combining data and video to be scaled within limited time and budget.
The UR75 is particularly suitable for smart grids, digital media installations, industrial automation, telemetry equipment, medical devices, digital factories, financial services, payment devices, environmental protection, water conservancy, and other applications.2x SIM Slots
- 5x RJ45 Gigabit Ethernet
- 1x RS232
- 1x RS485
- 1x Digital Input
- 1x Digital Output
- 6x External Antennas (Cellular/GPS/WiFi)
- 1x USB 2.0
- 1733 Gbps (2,4 / 5 GHz Wi-Fi)
| Interfaces | SIM Slots | 2 | ||||
| Ethernet Ports | 5 × 10/100/1000 Mbps | |||||
| Serial Ports | 1 × RS232 + 1 × RS485 | |||||
| DI/DO | 1 × DI + 1 × DO | |||||
| Voice | N/A | |||||
| Antenna Connectors | 3 x Cellular Connectors 1 x Cellular/GPS Connector 2 x Wi-Fi Connectors | |||||
| Network | Cellular | 5G, 4G CAT4/6/9/12/20 (Optional) | ||||
| Wi-Fi | IEEE 802.11b/g/n/ac | |||||
| Serial Port | Transparent (TCP Client/Server, UDP), Modbus Gateway (Modbus RTU to Modbus TCP), Modbus Master | |||||
| Network Protocols | PPP, PPPoE, SNMP v1/v2c/v3, TCP, UDP, DHCP, RIP v1/v2, OSPF, DDNS, VRRP, HTTP, HTTPS, DNS, ARP, QoS, SNTP, Telnet, VLAN, SSH | |||||
| AAA | RADIUS, TACACS+, LDAP, Local Authentication | |||||
| Firewall | URL Filtering/ACL/DMZ/Port Mapping/MAC Binding/SPI/DoS Protection | |||||
| Reliability | VRRP, WAN Failover, Dual SIM Backup | |||||
| VPN | OpenVPN, IPsec, PPTP, L2TP, DMVPN, GRE | |||||
| Maintenance | Management | Web, CLI, SMS, Watchdog, On-Demand Dial-Up | ||||
| Multilevel Authority | Multiple Levels of User Authority | |||||
| Capabilities | CPU | 716 MHz, Quad-Core ARM Cortex-A7 | ||||
| Flash | 8 GB | |||||
| Memory | 512 MB DDR3 | |||||
| Built-in | Watchdog | |||||
| * GPS (Under Development) | GPS + GLONASS | |||||
| Extended Storage | 1 × M.2 NVMe SSD Slot | |||||
| Hardware | Power Input | 9 ~ 48 VDC | ||||
| Power Output (Optional) | 4 × 802.3af/at PoE PSE | |||||
| Ingress Protection | IP30 | |||||
| Housing & Weight | Metal, 525 g (1.16 lb) | |||||
| Dimensions | 135 × 118 × 45 mm (5.31 × 4.65 × 1.77 in) | |||||
| Mounting | Desktop, Wall, or DIN Rail Mounting | |||||
| Other Specifications | Operating Temperature | -40°C to +70°C (-40℉ to +158℉) Reduced cellular performance above 60°C | ||||
| Storage Temperature | -40°C to +85°C (-40℉ to +185℉) to +185℉)℉)) | |||||
| Relative Humidity | 0% to 95% (non-condensing) at 25°C/77℉ | |||||
| Certifications | RoHS, CE, FCC | |||||
| Frequency Band | E | LTE: B1/B3/B5/B7/B8/B20/B38/B40/B41 | 3G: B1/B5/B8 | GSM: B3/B8 | ||
| AF | LTE: B2/B4/B5/B12/B13/B14/B66/B71 | 3G: B2/B4/B5 | / | |||
| AU | LTE: B1/B2/B3/B4/B5/B7/B8/B28/B40 | 3G: B1/B2/B5/B8 | GSM: B2/B3/B5/B8 | |||
| 500GL* | N1/N2/N3/N5/N7/N8/N12/N20/N28/N41/N66/N71/N77/N78/N79 | LTE FDD: B1/B2/B3/B4/B5/B7/B8/B9/B12/B13/B14/B17/B18/B19/B20/B21(TBD) /B25/B26/B28/B29/B30/B32/B66/B71 LTE TDD: B34/B38/39/B40/B41/B42/B48 | ||||
